  11. Rigid Plate Shock-Absorbing Castr, 550 lb
Zoro Select Rigid Plate Shock-Absorbing Castr, 550 lb GDS-150A-RF - main

Rigid Plate Shock-Absorbing Castr, 550 lb

  • Mfr # GDS-150A-RF

  • Zoro # G3503315

product price: $165.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Rigid
Wheel/Tread Material
Polyurethane
Caster Brake Type
No Brake
Wheel Dia.
6 in
Wheel Width
1 5/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
GDS-150A-RF
Zoro #
G3503315
UPC #
-
Country of Origin
United States

Dimensions

Wheel Dia.
6 in
Wheel Width
1 5/8 in
Mounting Height
9 1/16 in
Mounting Plate Size
3 3/4 in x 3 3/4 in
Mounting Plate Thickness
6 1/2 mm
Mounting Bolt Dia.
3/8 in
Overall Height
9-1/16in
Overall Wheel Width
6 in
Bolt Hole Spacing - Length
10 mm
Mounting Plate Width
95 mm
Bolt Hole Spacing - Width
11 mm
Mounting Plate Length
95 mm

Details

Item
Plate Caster
Caster Sub-Type
Rigid
Wheel/Tread Material
Polyurethane
Caster Brake Type
No Brake
Load Rating
550 lb
Wheel Bearing Type
Ball
Wheel/Tread Color
Clear
Wheel Hardness Rating
90 Shore A
Number of Mounting Holes
4
Tread Shape
Donut
Caster Frame Material
Aluminum
Core Color
Gray
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
2-3/4 in x 2-3/4 in
Inside Bolt Hole Spacing
2-3/4 in x 2-3/4 in
Caster Plate Hole Pattern
D
Wheel Color
Clear
Includes
Mounting Hardware
Caster Brake Included
No
Caster Temp. Range Available
Yes
Frame Finish
Powder Coated
Standards
ANSI, CE
Features
Shock Absorbing
Swivel Lock Type
No Lock Included
Load Rating Range
300 to 999 lb
Includes Thread Guards
Yes
Wheel/Tread Hardness Rating
Firm
Wheel Core Material
Aluminum
Swivel Raceway Type
Double Ball
Swivel Construction
Kingpinless
Wheel Type
Solid
Load Capacity - Maximum
550 lb
Brake Location
Face
Mounting Plate Shape
Rectangle
Mounting Hole Type
Hole
Caster Features
Shock-Absorbing
Wheel Core Type
Solid
Wheel Bearing Material
Steel
For Surface Type
Asphalt, Ceramic, Rubber, Tile, Vinyl, Wood
Operating Temperature - Maximum
190 Degrees F
Operating Temperature Range
14 Degrees to 194 Degrees F
Operating Temperature - Minimum
15 Degrees F

Description

Rigid, Plate Caster, Load Rating 550 lb, Swivel Lock Type No Lock Included, Wheel Dia. 6 in, Wheel Width 1 5/8 in, Wheel/Tread Material Polyurethane, Wheel Core Material Aluminum, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Donut
