Self-Drilling Screw, #8 x 5/8 in, Zinc Plated Steel Pan Head Phillips Drive, 100 PK

  • Mfr # U31820.016.0062

  • Zoro # G0815211

product price:
$
2.99
/pk of 100, $0.03/ea

Key Features

Pan Head
Phillips Drive
Drilling Tip
System of Measurement
Inch
Drive Size
#2
Material
Steel
Finish
Zinc Plated
Materials for Use With
Multi-Material
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
U31820.016.0062
Zoro #
G0815211
UPC #
-
Country of Origin
Multiple

Dimensions

Screw Size
#8
Fastener Length
5/8 in
Drive Size
#2
Head Dia.
0.322 in to 0.306 in
Drill Point Length
0.211 in
Head Height
0.11 in
Drill Point Size
2
Maximum Head Width
21/64 in
Drill Tip Length
7/32 in
Head Width
0.322 in
Overall Length
5/8 in
Maximum Head Height
7/64 in
Washer Outside Diameter
0.348 in
Thread Size
#8-18
Wire Rope Length
5/8 in

Details

System of Measurement
Inch
Head Type
Pan
Drive
Phillips
Tip Type
Drilling
Material
Steel
Finish
Zinc Plated
Materials for Use With
Multi-Material
Thread Style
Fully Threaded
Item
Self-Drilling Screw
Standards
IFI 113, SAE J78
Application
Steel to Steel
Head Color
Silver
Point Type
BSD
Dimensional Standards
RoHS Compliant
Type
Self-Drilling Screw
Pack Size
Small
Material Quality Standards
SAE J429

Description

The ZORO SELECT - U31820.016.0062 is a self-drilling screw that can be used to attach various materials to metal. Made from steel, this fastener is equipped with a drill point at the end, allowing it to be driven directly into materials without the need for pre-drilled holes. The zinc-plated finish is intended to improve durability and corrosion resistance, potentially improving grip or reducing friction during installation.

  • Drive: Phillips drive type means that a Phillips tool will be needed for installation or removal.
  • Drive Size: A #2 size tool fitting is required to install or remove this self-drilling screw.
  • Fastener Length: With a length of 5/8 in, it determines how deeply it can penetrate and secure materials together.
  • Head Type: Pan head type may be compatible with specific tools and suitable for certain materials and applications.
  • Screw Size: #8 screw size refers to its width and thread count, which can influence how it fits into materials in industrial applications.
  • Standards Compliance: Adheres to IFI 113, SAE J78 standards indicating compliance with established technical specifications for design, safety, and performance
  • Thread Style: Fully threaded style implies that threads run along the entire length of the screw, which could contribute towards hold strength when fastening material together
