Split Taper Bushing, 4 7/8" Flange W
Mfr # R2x2-15/16
Zoro # G514563944
product price:Â $164.99
/ea
Free Shipping & Returns
Key Features
Bore Bushing Series
R2
Length
4.875 in
Material
Steel
Flange Type
Solid
Includes
(3) Cap Screws
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- R2x2-15/16
- Zoro #
- G514563944
- UPC #
- 00195057383869
- Country of Origin
- China
Dimensions
- Length
- 4.875 in
- Bore Diameter
- 2 15/16 in
- Flange Width
- 5/8 in
- Barrel Diameter
- 3.75 in
- Bushing Diameter
- 4 in
- Overall Diameter
- 5.375 in
- Length Less Flange
- 4.25 in
- Bolt Circle Diameter
- 4.63 in
- Keyway Height
- 3/8 in
- Keyway Width
- 3/4 in
Details
- Bore Bushing Series
- R2
- Material
- Steel
- Flange Type
- Solid
- Includes
- (3) Cap Screws
- Taper
- 3/4 in Per ft
- Item
- Split Taper Bushing
- Fastener Tightening Torque Capacity
- 348 lb-in
- Bushing Type
- Split Taper
- System of Measurement
- Inch
- For Shaft Type
- Keyed
Description
Split Taper Bushing, Bushing Type Split Taper, Bore Bushing Series R2, Bore Diameter 2 15/16 in, Length 4.875 in, Bolt Circle Diameter 4.63 in, Bolt Size Not Applicable, System of Measurement Inch, Bushing Diameter 4 in, Fastener Tightening Torque Capacity 348 lb-in, Flange Type Solid, Flange Width 5/8 in, For Shaft Type Keyed, Includes (3) Cap Screws, Keyway Height 3/8 in, Keyway Width 3/4 in, Length Less Flange 4.25 in, Material Steel, Overall Diameter 5.375 in, Taper 3/4 in Per ft
