Swivel NSF-Listed Plate Caster, 4 in Dia, 700 lb, Blue

  • Mfr # P21S-U040D-14-BC-SS

  • Zoro # G4626124

product price:
$
57.19
/ea

Key Features

Thread Guards
No
Mounting Bolt Dia.
3/8 in
Core Color
Blue
Caster Plate Hole Pattern
B
Non-Marking
Yes
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
P21S-U040D-14-BC-SS
Zoro #
G4626124
UPC #
-
Country of Origin
China

Dimensions

Mounting Bolt Dia.
3/8 in
Stem Dia.
No Stem
Wheel Width
2 in
Overall Height
5-5/8"
Wheel Dia.
4 in
Mounting Height
5 5/8 in
Mounting Plate Size
4in x 4-1/2in
Swivel Radius
3-3/8 in
Overall Wheel Width
2 in
Inside Slot Spacing - Length
3 in
Mounting Plate Length
4 in
Outside Slot Spacing - Length
3.625 in
Mounting Plate Thickness
7/32 in
For Axle Dia.
1/2 in
Inside Slot Spacing - Width
2.625 in
Outside Slot Spacing - Width
3 in

Details

Thread Guards
No
Core Color
Blue
Caster Plate Hole Pattern
B
Non-Marking
Yes
Caster Sub-Type
Swivel
Includes
Top and Bottom Grease Seals
Caster Frame Material
Steel
Item
Plate Caster
Outside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Number of Wheels
1
Caster Brake Included
No
Extended Lead
No
Standards
ANSI ICWM, NSF Listed
Caster Stem Type
No Stem/Plate Included
Wheel Color
Blue
Caster Temp. Range Available
Yes
Frame Finish
Powder Coated
Load Rating
600 lb
Application
Food Processing, Food Service, Hospitality, Institutional, Pharmaceuticals
Inside Bolt Hole Spacing
3 in x 3 in
Caster Mounting Type
Plate
Caster Brake Type
No Brake
System of Measurement
Inch
Tread Color
Blue
Replacement Wheel
Mfr. No. P-U-040x020/050D-001
Tread
Standard
Wheel Bearing Type
Delrin
Includes Thread Guards
No
Swivel Construction
Kingpin
Wheel/Tread Hardness Rating
Hard
Swivel Lock Type
No Lock Included
Tread Shape
Standard
Wheel Core Material
Polyurethane
Swivel Raceway Type
Double Ball
Number of Mounting Holes
4
Load Rating Range
Light-Medium Duty
Wheel/Tread Material
Polyurethane
Wheel/Tread Color
Blue
Load Capacity
1000 lb
Series
P21 Series
Resistant To
High Chemical Resistance To Many Aggressive Substances
Accessories
Optional: P-DL21-14 (Directional Lock)
ESD Conductive
No
Load Capacity - Maximum
1,000 lb
Wheel Hardness Rating
60 Shore D
Wheel Core Type
Solid
Mounting Plate Shape
Rectangle
For Surface Type
Asphalt, Ceramic, Grease, Oil, Rubber, Steel, Tile, Vinyl, Wood
Caster Features
Corrosion-Resistant, Debris-Resistant, Maintenance Free, Quiet-Roll
Mounting Hole Type
Slot
Wheel Bearing Material
Delrin
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature Range
-40 Degrees to 180 Degrees F
Operating Temperature - Maximum
180 Degrees F

Description

Swivel, Plate Caster, Load Rating 600 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Polyurethane, Wheel Core Material Polyurethane, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
