  11. Swivl Plat Castr, Polyolfin, 5 in, 220 lb, D
Shop All Plate Casters
Zoro Select

Swivl Plat Castr, Polyolfin, 5 in, 220 lb, D

original price: $9.69
14% off
new price: $8.25
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Caster Brake Included No
  • Caster Load Rating Range Light-Duty
  • Caster Sub-Type Swivel
  • Caster Wheel Shape Standard
  • Caster Wheel/Tread Material Polyolefin
See all product information

Product Information

Dimensions

Overall Height 5-5/8"
Wheel Dia. 5 in
Wheel Width 1 1/4 in
Stem Dia. No Stem
Mounting Bolt Dia. 5/16 in
Caster Plate Size 2-3/4" x 3-3/4"
Plate Size 2-3/4" x 3-3/4"
Mounting Plate Size 2 3/4 in x 3 3/4 in
Mounting Height 5 3/4 in

Details

Caster Brake Included No
Caster Load Rating Range Light-Duty
Caster Sub-Type Swivel
Caster Wheel Shape Standard
Caster Wheel/Tread Material Polyolefin
Load Rating 220 lb
Number of Wheels 1
Caster Stem Type No Stem/Plate Included
Durometer 65 Shore D
Frame Finish Zinc Plated
Caster Plate Hole Pattern D
Inside Bolt Hole Spacing 1-3/4 in x 3 in
Caster Raceway Double Ball
Plate Caster Bolt Hole Pattern D
Caster Temp. Range Available No
Frame Material Steel
Wheel Color Black
Outside Bolt Hole Spacing 1-3/4 in x 3 in
Item Standard Plate Caster
Caster Wheel Bearings Delrin
Caster Plate Thickness 7/64"
Plate Thickness 7/64"
Caster Frame Material Steel
Standards ANSI ICWM
Thread Guards No
Caster Product Group Swivel Caster
Caster Core Material Polypropylene
Core Color Gray
Caster Swivel Lock Type No Lock Included
Caster Brake Type No Brake Included
Non-Marking Yes
Load Rating Range 0 to 299 lb
Includes Thread Guards No
Swivel Raceway Type Double Ball
Mounting Plate Bolt Hole Pattern D
Swivel Construction Kingpin
Wheel Core Material Plastic
Wheel Bearing Type Delrin
Swivel Lock Type No Lock Included
Number of Mounting Holes 4
Wheel/Tread Hardness 65 Shore D
Wheel/Tread Hardness Rating Hard
Tread Shape Standard
Wheel/Tread Material Polyolefin
Wheel/Tread Color Black

Description

Swivel, Standard Plate Caster, Load Rating 220 lb, Swivel Lock Type No Lock Included, Wheel Dia. 5 in, Wheel Width 1 1/4 in, Wheel/Tread Material Polyolefin, Wheel Core Material Plastic, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake Included, Tread Shape Standard
