Taper Lock Bushing, Flangeless
Mfr # 1610x15mm
Zoro # G014642477
product price:Â $17.59
/eaKey Features
Bore Bushing Series
1610
Length
1 in
Flange Type
Flangeless
Includes
(2) Set Screws
Taper
8 Degrees
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
1610x15mm
Zoro #
G014642477
UPC #
00195057291256
Country of Origin
China
Dimensions
Length
1 in
Overall Diameter
2.25 in
Bolt Circle Diameter
2.13 in
Bore Diameter
15 mm
Keyway Width
5 mm
Keyway Height
2.4 mm
Details
Bore Bushing Series
1610
Flange Type
Flangeless
Includes
(2) Set Screws
Taper
8 Degrees
Material
Steel
Item
Taper Lock Bushing
Maximum Torque
4,300 in-lb
For Shaft Type
Keyed
Bushing Type
Taper Lock
System of Measurement
Metric
Description
Taper Lock Bushing, Bushing Type Taper Lock, Bore Bushing Series 1610, Bore Diameter 15 mm, Length 1 in, Bolt Circle Diameter 2.13 in, Bolt Size Not Applicable, System of Measurement Metric, Bushing Diameter Not Applicable, Flange Type Flangeless, Flange Width Not Applicable, For Shaft Type Keyed, Includes (2) Set Screws, Keyway Height 2.4 mm, Keyway Width 5 mm, Length Less Flange Not Applicable, Material Steel, Overall Diameter 2.25 in, Taper 8 Degrees
