Variable Pitch V-Belt Pulley
- Mfr # 1VL40X5/8
- Zoro # G410987127
product price:Â
$
23.45
/ea
Key Features
Number of Grooves
1
Material
Cast Iron
Material Fabrication
Cast
Outside Diameter
3.75 in
Weight
1.3 lb
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 1VL40X5/8
- Zoro #
- G410987127
- UPC #
- 00195057185371
- Country of Origin
- China
- Number of Grooves
- 1
- Material
- Cast Iron
- Material Fabrication
- Cast
- Weight
- 1.3 lb
- Standards
- REACH Certification, RoHS Compliant
- Item
- Variable Pitch V-Belt Pulley
- Number of Turns
- 4 (3L); 5 (4L, A); 6 (5L, B)
- Pulley Construction
- Plain
- For V-Belt Type
- Wedge, Cogged
- Pulley Industry Number
- 1VL40
- Shell Material
- Cast Iron
- Traction Material
- Cast Iron
Dimensions
- Outside Diameter
- 3.75 in
- For Belt Trade Size
- 3L, 4L, 5L, A, AX, B, BX
- Bore Diameter
- 5/8 in
- Overall Width
- 1 11/16 in
- AX Pitch Diameter (Minimum)
- 2.4 in
- AX Pitch Diameter (Maximum)
- 3.4 in
- 4L Pitch Diameter (Minimum)
- 2.4 in
- B Pitch Diameter (Maximum)
- 3.7 in
- 3L Pitch Diameter (Minimum)
- 2.3 in
- A Pitch Diameter (Maximum)
- 3.4 in
- BX Pitch Diameter (Maximum)
- 3.7 in
- A Pitch Diameter (Minimum)
- 2.4 in
- 5L Pitch Diameter (Minimum)
- 2.7 in
- 4L Pitch Diameter (Maximum)
- 3.4 in
- 3L Pitch Diameter (Maximum)
- 3.1 in
- BX Pitch Diameter (Minimum)
- 2.7 in
- Maximum Pitch Diameter
- 3.1 in (3L), 3.4 in (4L, A), 3.7 in (5L, B)
- 5L Pitch Diameter (Maximum)
- 3.7 in
- B Pitch Diameter (Minimum)
- 2.7 in
- Minimum Face Width
- 0.703 in
- Keyway Width
- 3/16 in
- Minimum Pitch Diameter
- 2.3 in (3L), 2.4 in (4L, A), 2.7 in (5L, B)
- Keyway Depth
- 3/32 in
- Maximum Face Width
- 1.094 in
- Length through Bore
- 1 11/16 in
Description
Variable Pitch V-Belt Pulley, Bore Diameter 5/8 in, Standards REACH Certification, RoHS Compliant, For Belt Trade Size 3L, 4L, 5L, A, AX, B, BX, For V-Belt Type Wedge, Cogged, Material Cast Iron, Maximum Pitch Diameter 3.1 in (3L), 3.4 in (4L, A), 3.7 in (5L, B), Number of Grooves 1, Outside Diameter 3.75 in, Set Screw Location Not Applicable, 3L Pitch Diameter (Maximum) 3.1 in, 3L Pitch Diameter (Minimum) 2.3 in, 3V Pitch Diameter (Maximum) Not Applicable
