Ring Terminal, #6 Stud Size, 14 AWG, 600 V, Nylon Insulated, Blue
Mfr # RB14-6
Zoro # G1111906
product price:Â $2.15
/ea
Sold in multiples of 4 for $8.60
Key Features
Insulation Color
Blue
Maximum Wire Size
14 AWG
Insulation Type
Nylon
Stud Size
#6
Contact Material
Copper
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- RB14-6
- Zoro #
- G1111906
- UPC #
- 78621080402
- Country of Origin
- Unknown
Dimensions
- Maximum Wire Size
- 14 AWG
- Stud Size
- #6
- Overall Length
- 0.89 in
- Tongue Width
- 0.31 in
- Minimum Wire Size
- 18 AWG
Details
- Item
- Ring Terminal
- Insulation Color
- Blue
- Insulation Type
- Nylon
- Contact Material
- Copper
- Maximum Voltage
- 600 V
- Maximum Operating Temperature
- 105 Degrees C
- Standards
- UL Listed E9809
- Features
- Self-insulated with high dieletric-strength nylon sleeves.; An inner bronze insulation grip sleeve lengthens the flexing radius of the conductor and eliminates conductor creep.; Application Tools: WT2000, WT112M, WT145C, ERG4001, WT145A; Alternate Package Qty: RB853
- Insulation Dia
- 0.162 in
- Special Features
- Self-insulated with high dieletric-strength nylon sleeves. An inner bronze insulation grip sleeve lengthens the flexing radius of the conductor and eliminates conductor creep.
- Surface protection
- Tinned
- Insulation Coverage
- Partial Coverage
- Termination Style
- Crimp Termination Only
- Terminal Shape
- Ring
