Shop ACME ELECTRIC

Drive Isolation Transformer, 7.5 kVA, NEMA 3R, 266/460V, 575V

  • Mfr # DTHB72S

  • Zoro # G3714897

product price:
$
1,904.99
/ea
Additional $150.00 delivery surcharge applies per item.
See details

Key Features

Input Voltage - Transformer
575V
Output Voltage
266/460V
Power Rating
7.5 kVA
Phase
3
Mounting - Transformer
Wall
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
DTHB72S
Zoro #
G3714897
UPC #
-
Country of Origin
China

Dimensions

Overall Height
15.21 in
Overall Width
19 1/4 in
Overall Depth
7.37 in

Details

Item
Drive Isolation Transformer
Input Voltage - Transformer
575V
Output Voltage
266/460V
Power Rating
7.5 kVA
Phase
3
Mounting - Transformer
Wall
Hz - Electrical
60 Hz
NEMA Enclosure Rating
NEMA 3R
Winding Material
AL
Temperature Rise
115 deg C
Winding Material - Transformer
Aluminum
UL Insulation Class
180°C
UL Standard
UL 506
BNFC Taps
1
Taps % Steps
0.05
Primary Voltage
575D V
CSA Standard
C22.2 No. 47
Max Temperature Rise
115 Degrees Celsius
ANFC Taps
1
Material type
ZFIN
Electrostatic Shield
Shielded
Construction
Encapsulated
Features
Copper terminations for trouble free operation; Wound Core and Strip Winding for Low Losses; Electrostatic shield for enhanced protection
Product Category
Drive Isolation Transformer

Description


1


  • • Copper terminations for trouble free operation

  • • Wound Core and Strip Winding for Low Losses

  • • Electrostatic shield for enhanced protection

  • • Full capacity taps on all units
