- Item
- Power Inverter
- Peak Output Power
- 2500 W
- Continuous Output Power
- 1,250 W
- Inverter Output Form
- Modified Sine
- Inverter Input Voltage
- 12V DC
- Inverter Output Voltage
- 120V AC
- Outlet Type
- Standard 3-Prong
- DC Connection
- Battery Cables
- Number of Outlets
- 2
- Features
Features: Specifications: *May cause lines or waves on your TV. If you don’t want any interference consider our pure sine wave line.;1250W continuous power. Use 150 amp inline fuse.;3500W surge power;Modified sine wave;Green LED to confirm power on;Red overload LED;2 ac receptacles;Over Temperature protection alarm and shutdown at 55 + or – 5°C;Over Load protection;cooling fan;ac output short circuit protection;Auto reset on most fault conditions;12 Volt DC (10-15V);120 Volt AC;60 Hz;>90% Efficiency;No load: .6 amps at 12.5 volts or higher;Dimensions (LXWxH): 10.5" x 5.25" x 3.25";Weight: Unit – 3.3 lbs Boxed – 4 lbs;Instruction manual;Free 1 year tech support;1 Year Warranty Parts and Labor
- Nominal Output Power
- 1,250 W
- Inveter Output Voltage
- 120V AC
- Specification
Specifications;*May cause lines or waves on your TV. If you don’t want any interference consider our pure sine wave line.;ac output short circuit protection;Auto reset on most fault conditions;12 Volt DC (10-15V);120 Volt AC 60 Hz;>90% Efficiency;No load: .6 amps at 12.5 volts or higher;Dimensions (LXWxH): 10.5" x 5.25" x 3.25";Weight: Unit – 3.3 lbs Boxed – 4 lbs;Instruction manual;Free 1 year tech support;1 Year Warranty Parts and Labor
- Battery Low Shutdown
- DC 9.5 +_ 0.5 V
- For Use With
- 12 Volt Back up systems
- Fan
- Thermal
- Includes
- Power inverter, instruction manual
- Surge Power Capacity
- 3100W for 40milsecs
- Output Wave Form
- Modified Sine Wave
- Shape
- Rectangle
- Mounting Hole Location
- 2-5/8 center hole to center hole
- Application
- Backup power, work trucks, work sites, RV
- Color
- Grey
- Efficiency
- Over 90%
- Operating Temperature (Automatic Recovery/Shutdown)
- 30-130° F
- Capacity
- 1250 Watts
- Case Material
- Metal Enclosure
- Internal DC Input Fuse
- Must be fitted use 25A*3 max
- No Load Current
- 0.6 A
- Battery Low Alarm
- DC 10.5 +_ 0.5 V
- Power Switch
- DC input ON/OFF control
- DC Input Voltage
- 12V (10-15V)
- Remote Switch Port
- No
- Voltage
- 12 V
