  5. 24x24x2 Pleated Air Filter, High Capacity, Synthetic, MERV 10, 3.0 to 10.0 microns

This item is Discontinued.

Air Handler 24x24x2 Pleated Air Filter, High Capacity, Synthetic, MERV 10, 3.0 to 10.0 microns 3GRU4

24x24x2 Pleated Air Filter, High Capacity, Synthetic, MERV 10, 3.0 to 10.0 microns (Discontinued)

  • Mfr # 3GRU4
  • Zoro # G3775965
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
3GRU4
Zoro #
G3775965
UPC #
190735017234
Country of Origin
Multiple

Dimensions

Nominal Filter Size
24x24x2
Actual Filter Size
23-3/8 in x 23-3/8 in x 1-3/4 in
Nominal Height
24 in
Nominal Width
24 in
Nominal Depth
2 in
Actual Depth
1 3/4 in
Actual Width
23 3/8 in
Actual Height
23 3/8 in

Details

Performance Rating
MERV 10
Air Filter Capacity
High Capacity
Filters Out
Auto Emission Particulates, Coal Dust, Humidifier Dust, Lead Dust, MERV 9-12 Legionella, Milled Flour, Nebulizer Droplets
Air Filter Item
High Capacity Diamond Pleated Filter
Air Flow @ 300 fpm
1,200 cfm
Frame or Header Material
Beverage Board
Filter Efficiency
40%
Media Material
Synthetic
Filter Frame Color
White
Air Flow @ 500 fpm
2,000 cfm
Item
Pleated Air Filter
Final Recommended Resistance
1.0 in in wc
Initial Resistance @ 500 fpm
0.33 in wc
Max. Temp.
180 Degrees F
Max. Velocity
500 fpm
Media Color
White
MERV
10
Media Area
17.6 sq ft
High Initial Resistance
0.24"WC
Style - Air Filters
Panel
Common Applications
High Strength
Gasket Location
None
Standards
UL 900 Classified
Initial Resistance @ 300 fpm
0.20 in wc
Pleats per Linear Foot
29
Frame Included
Yes
Removes Particles Down To
3.0 to 10.0 microns
High Velocity
500 fpm
Filter Efficiency - Air Filters
50 %
Frame Type
Moisture Resistant Die Cut Chipboard
Avg. Atmospheric Efficiency
60 to 65%
Gasket Material
None
Air Filter Media Type
Synthetic
Material
Polyester

Description

Pleated Air Filter, Style - Air Filters Panel, Performance Rating MERV 10, Nominal Filter Size 24x24x2, Filter Efficiency - Air Filters 50 Percent, Air Filter Capacity High Capacity, Media Material Synthetic, Frame or Header Material Beverage Board, Common Applications High Strength, Media Color White, Media Area 17.6 sq ft, Pleats per Linear Foot 29, Filters Out Auto Emission Particulates, Coal Dust, Humidifier Dust, Lead Dust, MERV 9-12 Legionella, Milled Flour, Nebulizer Droplets
