4" X 2" Non-Marking Polyurethane X-Treme Swivel Caster, Total Lock Brake, Loads Up To 1000 lb

  • Mfr # 16XI04201ST
  • Zoro # G500712851
product price:
$
127.99
/ea
Free Shipping & Returns

Key Features

Wheel/Tread Material
Polyurethane
For Axle Dia.
1/2 in
Caster Mounting Type
Plate
Operating Temperature Range
Up to 180 Degrees F
Caster Frame Material
Steel
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
16XI04201ST
Zoro #
G500712851
UPC #
-
Country of Origin
United States

Dimensions

For Axle Dia.
1/2 in
Mounting Height
5 5/8 in
Wheel Dia.
4 in
Mounting Bolt Dia.
3/8 in
Mounting Plate Thickness
1/4 in
Wheel Width
2 in
Mounting Plate Size
4 in x 4 1/2 in
Swivel Radius
6 9/16 in
Hub Length
2 3/16 in
Inside Slot Spacing - Width
2.625 in
Outside Slot Spacing - Length
3.625 in
Mounting Plate Length
4 1/2 in
Inside Slot Spacing - Length
3 in
Outside Slot Spacing - Width
3 in
Mounting Plate Width
4 in
Fits Chest Size
Zinc Plating Provides An Attractive Finish Which Increases Corrosion Resistance and Provides Longer Caster Life

Details

Wheel/Tread Material
Polyurethane
Caster Mounting Type
Plate
Operating Temperature Range
Up to 180 Degrees F
Caster Frame Material
Steel
Application
Distribution Carts, Dollies, Floor Trucks, Platform Trucks, Warehouse Trucks, Waste Disposal Trucks
Features
Zinc Plating Provides An Attractive Finish Which Increases Corrosion Resistance and Provides Longer Caster Life
Swivel Lead
1 11/16 in
Swivel Raceway Type
Double Ball
Frame Construction
Cold Forged
Item
Plate Caster
Frame Finish
Zinc Plated
Includes Thread Guards
No
Swivel Lock Type
No Lock Included
Core Color
Green
Wheel/Tread Color
Green
Caster Brake Type
Total Lock
With Toe Plate
No
Wheel/Tread Hardness Rating
Soft
Wheel Core Type
Solid
Outside Bolt Hole Spacing
3 in x 3 5/8 in
System of Measurement
Inch
Non-Marking
Yes
Caster Plate Hole Pattern
B
Caster Sub-Type
Swivel
Inside Bolt Hole Spacing
2 5/8 in x 3 in
Load Rating
1000 lb
Swivel Construction
Kingpin
Wheel Bearing Type
Roller
Wheel Core Material
Polyurethane
Tread Shape
Donut
Number of Mounting Holes
4
Number of Wheels
1
Includes Spanner Bushing
Yes
Load Rating Range
1000 to 2999 lb
Wheel Hardness Rating
70 Shore D
Load Capacity - Maximum
1,000 lb
Brake Location
Face
Mounting Hole Type
Slot
Mounting Plate Shape
Rectangle
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel, Tile, Wood

Description

Swivel, Plate Caster, Load Rating 1000 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Polyurethane, Wheel Core Material Polyurethane, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Total Lock, Tread Shape Donut
