  6. 4" X 2" Non-Marking Rubber Soft Flat Swivel Caster, No Brake, Loads Up To 350 lb
Albion 4" X 2" Non-Marking Rubber Soft Flat Swivel Caster, No Brake, Loads Up To 350 lb 18XS04229S - main

4" X 2" Non-Marking Rubber Soft Flat Swivel Caster, No Brake, Loads Up To 350 lb

  • Mfr # 18XS04229S

  • Zoro # G8093796

product price:  $127.25
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Swivel
Wheel/Tread Material
Rubber
Caster Brake Type
No Brake
Wheel Dia.
4 in
Wheel Width
2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
18XS04229S
Zoro #
G8093796
UPC #
-
Country of Origin
China

Dimensions

Wheel Dia.
4 in
Wheel Width
2 in
Mounting Height
5-5/8 in
Mounting Plate Size
4 in x 4 1/2 in
Mounting Plate Thickness
1/4 in
Mounting Bolt Dia.
3/8 in
For Axle Dia.
1/2 in
Outside Slot Spacing - Length
3.625 in
Mounting Plate Length
4 1/2 in
Inside Slot Spacing - Width
2.625 in
Outside Slot Spacing - Width
3 in
Inside Slot Spacing - Length
3 in
Mounting Plate Width
4 in

Details

Item
Swivel Caster
Caster Sub-Type
Swivel
Wheel/Tread Material
Rubber
Caster Brake Type
No Brake
Load Rating
350 lb
Caster Mounting Type
Plate
Wheel Bearing Type
Ball
Wheel/Tread Color
Grey
Wheel Hardness Rating
65 Shore A
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Grey
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
3 in X 3-5/8 in
Inside Bolt Hole Spacing
2-5/8 in X 3 in
Caster Plate Hole Pattern
B
Series
18 Series
Application
Picking Carts, Light Towing Carts, JIT Carts, AGV and Tow Line Applications
Swivel Bearing Seal Type
Sealed
Standards
ROHS Standards
Caster Stem Type
Top Plate
Operating Temperature Range
-45 to 180 Degrees F
Frame Finish
Zinc Plated
Frame Color
Gray
Swivel Raceway Type
Precision Ball
ESD Conductive
No
Swivel Lock Type
No Lock Included
Load Rating Range
300 to 999 lb
Wheel Core Type
Solid
Wheel/Tread Hardness Rating
Soft
Swivel Lead
1-11/16 in
Features
Ergonomic, Maintenance Free, Easier Push/Pull Force, Quieter Operation
Wheel Core Material
Polypropylene
NSF Listed
No
Swivel Construction
Swivel
Includes Thread Guards
No
Includes Spanner Bushing
Yes
Load Capacity - Maximum
350 lb
Mounting Plate Shape
Rectangle
For Surface Type
Asphalt, Ceramic, Metal Scrap, Rubber, Steel, Tile, Vinyl, Wood
Mounting Hole Type
Slot
Caster Features
Debris-Resistant, Maintenance Free, Quiet-Roll, Shock-Absorbing

Description

Swivel, Plate Caster, Load Rating 350 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Rubber, Wheel Core Material Polypropylene, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
