Fixed Rod End, SS, Black Oxide
Mfr # ZEBM6X80-BLACK
Zoro # G510723830
product price: $18.79
/eaKey Features
Type
Fixed Rod End
Thread Size
M6-1.00
Resistance Properties
Chemical Resistant, Corrosion Resistant
Overall Length
87 mm
System of Measurement
Metric
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
ZEBM6X80-BLACK
Zoro #
G510723830
UPC #
-
Country of Origin
United States
Dimensions
Thread Size
M6-1.00
Overall Length
87 mm
Shank Thread Length
66 mm
Head Outside Diameter
14 mm
Shank Thread Size
M6-1.0
Ball Diameter
6 mm
Head Width
7 mm
Bore Diameter
6 mm
Eye Thickness
7 mm
Hole Center-to-End Length
80 mm
Eye Outside Diameter
14 mm
Thread Length
66 mm
Screw Size
6 mm
Shank Diameter
6 mm
Shank Length
73 mm
Eye Inside Diameter
6 mm
Description
Fixed Rod End, Eye Inside Diameter 6 mm, Eye Outside Diameter 14 mm, Eye Thickness 7 mm, Black Oxide, Stainless Steel, Material Grade/Class 304, Material Quality Standards ASTM A582, REACH Compliant Yes, Hole Center-to-End Length 80 mm, RoHS Compliant Yes, Shank Diameter 6 mm, Thread Style Fully Threaded, Metric Coarse, Thread Direction Right Hand, Thread Length 66 mm, Thread Pitch 1 mm, Thread Size M6-1.00, Shank Length 73 mm, Externally Threaded, Shoulder Style Without Shoulder
