Fixed Rod End, Steel, Black Oxide
Mfr # ZEBM8X70LH-STL-BX
Zoro # G610723891
product price:Â
$
24.29
/ea
Key Features
Type
Fixed Rod End
Thread Size
M8x1.25
Ball Diameter
8 mm
Head Width
9 mm
Shank Thread Length
54 mm
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- ZEBM8X70LH-STL-BX
- Zoro #
- G610723891
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Thread Size
- M8x1.25
- Ball Diameter
- 8 mm
- Head Width
- 9 mm
- Shank Thread Length
- 54 mm
- Head Outside Diameter
- 18 mm
- Overall Length
- 79 mm
- Shank Thread Size
- M8-1.25
- Bore Diameter
- 8 mm
- Eye Outside Diameter
- 18 mm
- Eye Inside Diameter
- 8 mm
- Screw Size
- 8 mm
- Hole Center-to-End Length
- 70 mm
- Shank Diameter
- 8 mm
- Shank Length
- 61 mm
- Thread Length
- 54 mm
- Eye Thickness
- 9 mm
- Wire Rope Length
- 79 mm
- Minimum Thread Length
- 54 mm
- Length
- 79 mm
Description
Fixed Rod End, Eye Inside Diameter 8 mm, Eye Outside Diameter 18 mm, Eye Thickness 9 mm, Black Oxide, Steel, Material Grade/Class 12L14, Material Quality Standards ASTM A576, REACH Compliant Yes, Hole Center-to-End Length 70 mm, RoHS Compliant Yes, Shank Diameter 8 mm, Thread Style Fully Threaded, Metric Coarse, Thread Direction Left Hand, Thread Length 54 mm, Thread Pitch 1.25 mm, Thread Size M8x1.25, Shank Length 61 mm, Externally Threaded, Shoulder Style Without Shoulder
