  5. Digital Clamp Meter, LCD, 600 A, 1.4 in (36 mm) Jaw Capacity, CAT III 600V Safety Rating
Amprobe Digital Clamp Meter, LCD, 600 A, 1.4 in (36 mm) Jaw Capacity, CAT III 600V Safety Rating AMP-320 - main
Shop AMPROBE

Digital Clamp Meter, LCD, 600 A, 1.4 in (36 mm) Jaw Capacity, CAT III 600V Safety Rating

  • Mfr # AMP-320

  • Zoro # G9486461

product price:  $332.99
/ea
Free Shipping & Returns

Key Features

Digital/Analog
Digital
Max. AC Amps
600
Clamp Meter Jaw Style
Clamp On
Max. DC Volts
600 V
Max. Ohms
60,000
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AMP-320
Zoro #
G9486461
UPC #
095969770880
Country of Origin
Taiwan, Province of China

Dimensions

Max. Conductor Size
1.37 in (35.0mm)
Manufacturers Warranty Length
1 yr
Battery Size
AAA
Maximum Conductor Size
1.37 in (35.0mm)

Details

Item
Digital Clamp Meter
Digital/Analog
Digital
Max. AC Amps
600
Clamp Meter Jaw Style
Clamp On
Max. DC Volts
600 V
Max. Ohms
60,000
Jaw Capacity
1.4 in (36 mm)
Temp. Range
-40 Degrees to 752 Degrees F
Safety Rating
CAT III 600V
Display
LCD
Jaw Opening
1.4 in
Max. DC Amps
600
Max. AC Volts
600 V
AC Current Accuracy
+/-2.0% + 5 Digits
Non-Contact Voltage Detector
Yes
AC Response
TRMS
Bar Graph
No
Peak Hold
No
Audible Continuity
Yes
Counts
6,000
Thermometer Type
Type K Thermocouple
Auto Power Off
Yes
Auto Ranging
Yes
Capacitance
2,500 uF
Special Features
DC Micro Amps
Standards
CE, cULus
Diode Test
Yes
Includes
Carrying Case, K Type Banana Plug Thermocouple, Manual, Test Leads with Alligator Clips
Data Hold
Yes
Battery Type
AAA
Operating Temp.
32 Degrees to 104 Degrees F
Frequency Counter
5 Hz to 999.9 Hz
Inrush
Yes
Calibration Certificate
Not Included
Data Logging
Yes
Display Type
LCD
Basic AC Current Accuracy
+/-1.8% + 5LSD (50 to 60 Hz) +/-2.0% + 5LSD (100 to 400 Hz)
Inrush Current Measurable
Yes
Jaw Style
Clamp-Jaw
Bluetooth Compatible
No
Thermal Imaging
No
Bar Graph Included
No
Basic AC Voltage Accuracy
+/-1.0% + 5LSD (50 to 60 Hz)
Basic DC Current Accuracy
+/-2.0% + 5LSD (DC 50 to 100 Hz)
Maximum DC Current Measurement
600 A
Capacitance Measurement Accuracy
+/-2.0% + 4LSD
Basic DC Voltage Accuracy
+/-1.0% + 5LSD
Maximum Capacitance Measurement
2,500 uF
Calibration Certificate Included
No
Removable Screen
No
Maximum Operating Temperature
104 Degrees F
Frequency Measurement Accuracy
+/-1.00% + 5 LSD (600 V Range); +/-2.00% + 4 LSD (600 A Range)
Maximum Resistance Measurement
60,000 ohm
Dustproof
No
Minimum Operating Temperature
32 Degrees F
AC Response Calculation
TRMS
Resistance Measurement Accuracy
+/-1.0% + 5LSD
Intrinsically Safe
No
Maximum AC Voltage Measurement
600 V
Maximum AC Current Measurement
600 A
Current Leakage Testing
No
Parameters Measured
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature (K)
Instrument Counts
6,000
Waterproof
No
Maximum DC Voltage Measurement
600 V

Description

Digital Clamp Meter, Audible Continuity Yes, Safety Rating CAT III 600V, AC Response Calculation TRMS, Maximum AC Current Measurement 600 A, Maximum AC Voltage Measurement 600 V, Maximum DC Current Measurement 600 A, Maximum DC Voltage Measurement 600 V, Current Leakage Testing No, Parameters Measured AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature, Intrinsically Safe No, Dustproof No, Waterproof No, Data Logging Yes, Thermal Imaging No
