Hex Head Plug Hex Head Plug, 1/4" Pipe, Cast Iron, Class 150
- Mfr # 0318903564
- Zoro # G700714228
product price:Â
$
0.55
/ea
Key Features
Specific Fitting Shape
Plug
Pipe Fitting Material
Cast Iron
Pipe Size (Fittings)
1/4"
Standards
ASME B16.3, FM Approved, UL Listed
Temp. Range
-20 Degrees to 150 Degrees F
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 0318903564
- Zoro #
- G700714228
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Pipe Size (Fittings)
- 1/4"
- Nominal Pipe Size
- 1/4 in
Details
- Specific Fitting Shape
- Plug
- Pipe Fitting Material
- Cast Iron
- Item
- Plug
- Standards
- ASME B16.3, FM Approved, UL Listed
- Temp. Range
- -20 Degrees to 150 Degrees F
- Max. Steam Pressure
- 150 psi @ 350 Degrees F
- Plug Construction
- Solid
- Includes Seal
- No
- Includes Pre-Applied Thread Sealant
- No
- Plug Drive Style
- Hex
- Color
- Black
- Maximum Operating Pressure
- 300 psi @ 150 Degrees F
- Thread Type
- NPT
- Fitting Connection Type
- Threaded
- For Pipe Schedule
- Schedule 40, Schedule 80
- Maximum Operating Temperature
- 150 Degrees F
- Material Grade
- A197
- Minimum Operating Temperature
- -20 Degrees F
- Manufacture Location
- Made in USA
Description
Plug, 1/4 in Nominal Pipe Size, Cast Iron, Not Applicable, A197, Class Not Applicable, For Pipe Schedule Schedule 40, Schedule 80, Threaded, Not Applicable Overall Length, 300 psi @ 150 Degrees F Maximum Operating Pressure, 150 psi @ 350 Degrees F Max. Steam Pressure, -20 Degrees to 150 Degrees F, Plug Construction Solid, Plug Drive Style Hex, Includes Pre-Applied Thread Sealant No, Thread Sealant Type Not Applicable, Includes Seal No, Seal Material Not Applicable, Not Applicable, Not Applicable
