- Item
- UPS System
- VA Rating - UPS Systems
- 700.0 VA
- UPS Type
- Line Interactive
- Power Rating
- 700VA
- Mounting
- Floor
- Wattage
- 420 W
- Input Voltage
- 120V
- Output Voltage
- 120V
- Backup Time (Half/Full Load)
- 12 min 4 sec/3 min 23 sec
- Outlet Type
- (3) Surge; (3) UPS/Surge
- Medical Grade
- Not Medical Grade Approved
- Number of Outlets
- 6
- Includes
- USB Cables
- NEMA Plug Configuration
- 5-15P
- Fax/Modem Line Protection
- Yes
- Transfer Time
- 6 to 8 msec
- Standards
- ENERGY STAR V2.0, NOM, TUV
- Phase
- Single
- Input Current
- 12 A
- Hz
- 50/60 Hz (+/-3 Hz)
- Special Features
- Audible Alarms, Automatic Self Test, Cold-Start Capable, Predictive Failure Notification, Resettable Circuit Breaker, Serial Connectivity, Single Switched Outlet Group
- Footnotes
- 4,6
- NEMA Receptacle Configuration
- 5-15R
- Green Environmental Attribute
- Product is Rechargeable
- Display Type
- LCD
- Ports
- USB
- Automatic Volts Regulation
- No
- Voltage
- 120
- Input Connection
- NEMA 5-15P Plug
- Housing Material
- Steel
- Battery Type
- VRLA
- Housing Color
- Black
- Kw Rating
- 420 W
- Input Frequency
- 50/60 Hz +/- 3 Hz auto-sensing
- Battery Capacity
- 9.0 Ah
- Usb Compatible
- Yes
- Rated Power In Va
- 700 VA
- Switching Current Capacity
- 15 A
- Product Certifications
- NOM || TUV || ENERGY STAR V2.0 (USA)
- Data Line Protection
- Includes Data Line Surge Protection
- Ambient Air Temperature For Storage
- -15-45°C
- Online Thermal Dissipation
- 48.5 Btu/h
- Storage Altitude
- 0-50000 ft
- Provided Equipment
- User Manual || USB cable
- Operating Altitude
- 0...10000 ft
- Efficiency At Full Load
- 88...143 V
- Battery Voltage
- 12 V
- Ambient Air Temperature For Operation
- 0-40°C
- Acoustic Level
- 45 dBA
- Battery Life
- 3-5 year(s)
- Relative Humidity
- 0-95 %
- Waveform Type
- Stepped Sine Wave
- Hot Swappable
- Yes
- Product Series
- RS
- Load Capacity
- 700 VA/450 W
- Serial Port
- Yes
- USB
- Yes
- Package Contents
- Back-UPS RS 700 VA Tower UPS , USB cable, User manual
- Form Factor
- Tower
- Number of Battery & Surge Outlets
- 6
- Typical Battery Recharge Time
- 12 Hour
- Surge Energy Rating
- 354 J
- Efficiency
- View Efficiency Graph; action_new_window
- Battery Graph Comments
This graph is based on actual measured runtime data. All measurements were taken with new, fully charged batteries and a balanced resistive load (PF = 1.0). Actual runtimes may vary from the values of this graph. Actual runtimes are dependent on several variables including battery age, battery charge level, environmental conditions and characteristics of the connected load.
- Filtering
- Full time multi-pole noise filtering :5% of IEEE surge let-through : zero clamping response time: in
- RBC Quantity
- 1
- Maximum Input Current Per Phase
- 12 A
- Equipment Protection Policy
- Lifetime : $150000
- Redundant
- No
- Output Connection Type
- 3 NEMA 5-15R; 3 NEMA 5-15R surge
- Output Frequency
- 50/60 Hz +/- 3 Hz sync to mains
- Battery Charge Power
- 7 W rated
- Input Connection Type
- NEMA
- Input Current - Maximum
- 12 A
- Number of Outlets - UPS
- 6
- Plug Configuration
- 5-15P
- Power Rating - Real
- 420 W
- Receptacle Configuration
- 5-15R
- Operating Temperature - Minimum
- 32 Degrees F
- Surge Suppression Rating
- 354 J
- Includes Battery
- Battery Included
- Battery Recharge Time
- 12 hr
- Replacement Battery Part Number
- BATT17-1209, RBC17
- Battery Chemistry
- Valve Regulated Lead Acid
- Manufacturer Warranty
- 3 yr
- Operating Temperature - Maximum
- 104 Degrees F
- Transfer Time - Minimum
- 8 msec
- Transfer Time - Maximum
- 12 msec
- Output Ports Included
- USB
- Run Time - Full Load
- 4.98 min
- Power Rating - Apparent
- 700 VA
- Number of Outlets - Surge Only
- 3
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Battery Life - Minimum
- 3 yr
- External Battery Compatible
- Not External Battery Pack Compatible
- Frequency
- 50/60 Hz
- Run Time - Half Load
- 15.45 min
- Green Certification or Other Recognition
- ENERGY STAR(R) Certified
