No Product Image Available

Reduced Pressure Zone Backflow Preventer

  • Mfr # 4A206A2F

  • Zoro # G909534603

product price: $565.99
/ea
Free Shipping & Returns

Key Features

Body Material
Bronze
Temp. Range
33 Degrees F to 180 Degrees F
Width
5 1/8 in
Max. Temp.
180 Degrees F
Flow
99 gpm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
4A206A2F
Zoro #
G909534603
UPC #
670750109553
Country of Origin
United States

Dimensions

Width
5 1/8 in
Length
17 1/2 in
Size
1 1/4 in
Overall Height
9.88 in
Check Valve Length
11 3/4 in
Connection Size - Side 2
1 1/4 in
Connection Size - Side 1
1 1/4 in
Overall Width
5.13 in
Nominal Valve Size
1 1/4 in
Overall Length
17.5 in

Details

Body Material
Bronze
Temp. Range
33 Degrees F to 180 Degrees F
Max. Temp.
180 Degrees F
Flow
99 gpm
Spring Material
Stainless Steel
Includes
No Items
Compliance
ASSE 1013, AWWA C511, CSA B64.4, Federal Public Law 111-380, UL, ULC
Max. Pressure
175 psi
Connection
NPS
Seat Material
Silicone
Standards
Build America Buy America (BABA) Act, Buy American Act (BAA)
Mounting Orientation
Horizontal
Check Mechanism Material
Glass-Filled PPO
Connection Type - Side 2
NPT
Includes Atmospheric Vent
No Atmospheric Vent
For Media
Water
Includes Flood Protection
No Flood Protection
Maximum Pressure - Operating
175 psi
Manufacturer Warranty
5 yr
Operating Temperature - Minimum
33 Degrees F
Includes Freeze Sensor
No Freeze Sensor
Number of Test Ports
4
Cracking Pressure
5 psi
Handle Material
Stainless Steel
Connection Gender - Side 1
Female
Operating Temperature - Maximum
180 Degrees F
Shut-Off Valve Included
Ball Valve
Connection Gender - Side 2
Female
Backflow Preventer Type
Reduced Pressure Assembly (RP)
Includes Strainer
No Strainer
Connection Type - Side 1
NPSM
Hazard Protection Level
High Health Hazard
Valve Series
4A

Description

Reduced Pressure Zone Backflow Preventer

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
This is a restricted item in the USA. It cannot be used for potable water applications.
