  9. Steam Trap, 30 psi, 353F, 5-1/2 In. L
Shop All Steam Traps
Armstrong International

Steam Trap, 30 psi, 353F, 5-1/2 In. L

product price: $389.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • (F)NPT Connections 3/4 in
  • Max. Operating PSI 30 psi
  • End to End Length 5 1/2 in
  • Condensate Capacity Lbs/Hr 1,200 lb/hr
  • Max. Temp. 353 Degrees @ 125 psig
See all product information

Product Information

Dimensions

End to End Length 5 1/2 in
Overall Width 6 5/8 in
Overall Length 5 in
Overall Depth 5 5/8 in
Port Connection Size 3/4 in

Details

Item Steam Trap
(F)NPT Connections 3/4 in
Max. Operating PSI 30 psi
Condensate Capacity Lbs/Hr 1,200 lb/hr
Max. Temp. 353 Degrees @ 125 psig
Body Material Cast Iron
Pipe Configuration In-line
Application Steam Mains
Trap Position Horizontal
Type Float and Thermostatic
Air Vent Material Bronze/Stainless Steel
Operating Temperature - Maximum 353 Degrees F
Steam Trap Type Float & Thermostatic
Number of Ports 2
Includes Strainer Strainer Not Included
Distance Between Inlet and Outlet Port 5 1/2 in
Configuration In-line
Includes Air Vent Air Vent Included
Allowable Pressure - Maximum 125 psi
Float Material Cast Iron
Operating Pressure - Maximum 30 psi
Port Types Included Air Vent
Port Connection Gender Female
Condensate Capacity 1,200 lb/hr
Manufacturer Series BI
Port Connection Type NPT
Maximum Capacity at Maximum Pressure Load 1,200 lb/hr at 30 psi
Installation Orientation Horizontal

Description

Steam Trap, Air Vent Material Bronze/Stainless Steel, Allowable Pressure - Maximum 125 psi, Allowable Temperature - Minimum Not Applicable, Application Steam Mains, Body Material Cast Iron, Condensate Capacity 1,200 lb/hr, Configuration In-line, Distance Between Inlet and Outlet Port 5 1/2 in, Float Material Cast Iron, Includes Air Vent Air Vent Included, Includes Strainer Strainer Not Included, Installation Orientation Horizontal, Manufacturer Series BI
