Aro Solenoid Air Control Valve, 1/4 In, 24VDC CAT77S-024-L - main

Solenoid Air Control Valve, 1/4 In, 24VDC

  • Mfr # CAT77S-024-L

  • Zoro # G1528055

product price: $148.99
/ea
Free Shipping & Returns

Key Features

Voltage
24V DC
Coefficient of Volume
0.062
Valve Actuator / Return
Solenoid / Spring
Actuator/Return
Solenoid/Spring
Overall Height
3 9/16 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CAT77S-024-L
Zoro #
G1528055
UPC #
-
Country of Origin
United States

Dimensions

Overall Height
3 9/16 in
Pipe Size
1/4 in
Overall Length
2 5/32 in
Overall Width
1 1/4 in
Inlet Port Connection Size
1/4 in
Exhaust Port Connection Size
10-32
Pilot Port Connection Size
10-32

Details

Voltage
24V DC
Coefficient of Volume
0.062
Valve Actuator / Return
Solenoid / Spring
Actuator/Return
Solenoid/Spring
NEMA Classification
NEMA 4
Power Consumption
1.1 W
Normally Open / Normally Closed
Normally Closed
Body Style
Base-Mounted
Item
Solenoid Air Control Valve
Valve Ways and Positions
3-Way/2-Position
Pressure Range
0 to 150 psi
CFM
2.2
Max. CFM - Valves
2.2 cfm
Operational Pressure Range
0 to 150 psi
Ambient Temp. Range
0 Degrees to 122 Degrees F
Shifting Technology
Direct
Electrical Connections
DIN Connectors
Standards
CSA LR51090, UL MH13513
Air Valve Type
3-Way, 2-Position
Number of Ways
Three-Way
Operating Pressure - Maximum
150 psi
Spool Material
Stainless Steel
For Media
Air
Operating Temperature - Minimum
0 Degrees F
Vacuum Rating
Not Vacuum Operable
Valve Type
Poppet
Product Type
Solenoid Air Control Valve
Number of Positions
Two-Position
Exhaust Port Connection Type
NPT
Pilot Port Connection Type
NPT
Valve Action
Normally Closed
Inlet Port Connection Gender
Female
Body Material
Aluminum
Body Features
Stackable
Coefficient of Volume (Cv)
0.2
Actuator Type
Single Solenoid
Exhaust Port Connection Gender
Female
NEMA Rating
4
Includes Solenoid Coil
Solenoid Coil Included
Inlet Port Connection Type
NPT
Pilot Type
Internal Pilot
Fail Position
Closed
Response Time
9 msec
Override
Non-Locking
Includes Mounting Hardware
Hardware Not Included
Operating Temperature - Maximum
122 Degrees F
Series
CAT
Flow Rate - Maximum
6.9 cfm
Number of Ports
3
Electrical Connection Type
DIN Solenoid Connector
Operating Pressure - Minimum
0 psi
Pilot Port Connection Gender
Female
Return Action
Spring Return

Description

Solenoid Air Control Valve, Valve Ways and Positions 3-Way/2-Position, Voltage 24V DC, Center Position Not Applicable, Valve Actuator / Return Solenoid / Spring, ISO Class Not Applicable, Pipe Size 1/4 in, Max. CFM - Valves 2.2 cfm, Operational Pressure Range 0 to 150 psi, NEMA Classification NEMA 4, Normally Closed, Body Style Base-Mounted, Pilot Pressure Not Applicable, Coefficient of Volume 0.062, DIN Connectors Electrical Connections, Shifting Technology Direct, Power Consumption 1.1 W

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
