Solenoid Valve, 4-Way, 2-Position, Universal, 1/4 in Pipe Size, 120V AC, NAMUR Mount, Direct Acting

The ASCO - 8342G701 is a direct acting, 4-way/2-position solenoid valve featuring a NAMUR mount design. Constructed with a stainless steel body and PTFE seals, it controls the flow of air, inert gas, light oil, or water by using an energized coil to move the valve's plunger or poppet. Fluid compatibility: air, inert gas, light oil, or water. Standard coil configuration provided. Mounting orientations: horizontal or vertical.

Key Features:

• Nominal Pipe Size: 1/4 in
• Center Line Pipe Center Size: 3 in
• Orifice Diameter: 3/16 in
• Operating Pressure Differential (Maximum): 125 psi for Air/Inert Gas; 100 psi for Light Oil and Water
• Operating Pressure Differential (Minimum): 0 psi across Air/Inert Gas, Light Oil, and Water
• Fluid Temperature Maximum: 160°F
• Ambient Temperature Range: 32°F to 125°F
• Electrical Voltage: 120V AC at 60 Hz
• Wattage: 20.1 W
• Coil Insulation Class: F
• Coil Enclosure: Watertight, without junction box
• Electrical Connections: 1/2 in conduit with 18 in leads
• Environmental Rating: Indoor, Outdoor
• NEMA Enclosure Rating: 1, 2, 3, 3S, 4, 4X
• Inlet/Outlet Connection Type: NPTF Thread with NPT Thread Type
• Seal Material: PTFE
• Includes Coil and Seal
• Dimensions: Overall Height 4-7/16 in; Overall Length 2-1/16 in; Overall Width 1-15/16 in
• IP Rating: 66
• Standards: CSA, UL Listed
