Pressure Transducer, Range 0 to 5000 psi,

  • Zoro #: G0120915
  • Mfr #: G17MEK42DO5000#

$158.06

  • NEMA Rating: -
  • Operating Temp.: -40 to 257 F
  • Range: 0 to 5000 psi
See full product details
  • This item ships free.
  • Shipping & Returns
  • Sign up for Zmail and get 15% off your first order

Ashcroft #G17MEK42DO5000# Specifications

  • Zoro #: G0120915
  • Mfr #: G17MEK42DO5000#
NEMA Rating: - Operating Temp.: -40 to 257 F
Range: 0 to 5000 psi Power Required - Transmitters: 9 to 36VDC
Wetted Materials - Transmitters: Stainless Steel Loop Resistance: Dependent on Loop Supply Voltage
Max. Pressure (PSI): 7500 Operating Temp. - Transmitter: -40 Degrees to 257 Degrees F
Housing: 304 Stainless Steel Calibration Certificate: -
Process Connection: 7/16-20 SAE Male Accuracy: +/-0.5% Full Scale
Output: 4 to 20 mA at 12 to 30VDC Power Required: 9 to 36VDC
Process Connection Type - Transmitter: SAE Male Wiring Entry - Transmitter: 1/2" FNPT
For Use With: - Wetted Materials: Stainless Steel
Item: Pressure Transmitter Transmitter Type: Pressure Transmitter
Process Connection Size - Transmitter: 7/16"-20 Range Units - Transmitter: psi
Accuracy - Transmitter: +/-0.50% Full Scale Compatible With: Any Process Compatible with 316Stainless Steel
Electrical Connections - Transmitter: 4 Pin Hirschmann Style A DIN 43650-A Connector Thermal Error: +/-3% (-4 Degrees to 185 Degrees F)
Output - Transmitter: 4 to 20mA DC Includes: Instructions
Manufacturers Warranty Length: 1 yr. Range Values - Transmitter: 0 to 5000
Electrical Connections: DIN 43650-A Features: -
Country of Origin (subject to change): United States
Feedback Help us improve our product information

Description

Pressure Transmitter, Wetted Materials - Transmitters Stainless Steel, Range Values - Transmitter 0 to 5000, Range Units - Transmitter psi, Accuracy - Transmitter +/-0.50 Percent Full Scale, Electrical Connections - Transmitter 4 Pin Hirschmann Style A DIN 43650-A Connector, Power Required - Transmitters 9 to 36VDC, Process Connection Size - Transmitter 7/16 In.-20, Process Connection Type - Transmitter SAE Male, Output - Transmitter 4 to 20mA DC
