Power Supply, 400 to 500V AC, 24V DC, 720W, 30A, DIN Rail
Mfr # XCSG720C
Zoro # G412120324
Key Features
Specifications
Product Information
- MFR #
- XCSG720C
- Zoro #
- G412120324
- UPC #
- 813101021269
- Country of Origin
- Italy
Dimensions
- Overall Height
- 3.1 in
- Width
- 3.1 in
- Length (In.)
- 5 in
Details
- Item
- Power Supply
- Input Voltage
- 400 to 500V AC
- Output Voltage - Nominal
- 24V DC
- Output Power - Rated
- 720W
- Current - Output
- 30 A
- Mounting
- DIN Rail
- Phase
- Three
- Output Voltage
- 24V DC
- Power Rating
- 720W
- Phase - Electrical
- Three
- Output Amps
- 30A
- For Use With
- Electrical and Mechanical
- Amps
- 30 A
- Includes
- Power Supply
Description
The XCSG720C is a 30 Amp, 24V DIN rail mounted power supply with three-phase input. This 24Vdc, 30A DIN rail power supply has very compact dimensions saving valuable panel space. It provides 720 Watts or 30 Amps of 24Vdc power using a three-phase wide range 400to 500volt AC input that makes it applicable for use in North America or anywhere else in the world. The high-efficiency design of this 30A, 24Vdc DIN rail power supply is greater than 92% which provides for low dissipated power and long reliable life. It is cULus508 Listed and has features such as LED status indication, short circuit, over-temperature, input, and output overvoltage protection. The overload limit for the XCSG720C, 30A, 24Vdc DIN rail power supply is 45 A for greater than 5 seconds. The high outrush of this model makes it ideal in applications where heavy loads are powered.
- • 3 Phase
- • 30-Amp
- • LED Status Indication
