- Item
- UPS System
- VA Rating - UPS Systems
- 700.0 VA
- UPS Type
- Line Interactive
- Power Rating
- 700VA
- Mounting
- Floor
- Wattage
- 350 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V AC
- Backup Time (Half/Full Load)
- 10 min/2 min
- Outlet Type
- (4) Surge; (4) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 8
- Automatic Volts Regulation
- Yes
- Display Type
- No Display
- Phase
- Single
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Special Features
- Hot Swappable Batteries
- Fax/Modem Line Protection
- Yes
- Hz
- 60 Hz
- Standards
- CSA, FCC Part 15 Class A, NOM, RoHS, UL1778
- NEMA Plug Configuration
- 5-15P
- Input Current
- 12 A
- NEMA Receptacle Configuration
- (8) 5-15R
- Ports
- USB
- Transfer Time
- 2 to 4 msec
- Includes
- USB Cables
- Capacity - Batteries
- 700 VA/350 W
- Input Connection
- NEMA 5-15P Plug
- Battery Type
- VRLA
- Housing Material
- ABS
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 89 to 145
- Expandable Runtime
- No
- Input Phase
- Single-Phase
- AC Mode BTU / Hr. (Full Load)
- 61
- Output Watt Capacity (Watts)
- 350
- Internal UPS Replacement Battery Cartridge
- IMPORTANT BATTERY REPLACEMENT INFORMATION > If the original battery inside your AVR700U UPS has a rating of 12V 7AH, please order Tripp Lite RBC51 (quantity 1) replacement battery; If the original battery inside your AVR700U UPS has a rating of 12V 5AH, please contact Tripp Lite for assistance
- Individually Controllable Load Banks
- No
- Installation Form Factors Supported with Included Accessories
- Tower; Ultra-compact desktop; Wallmount
- Half Load Runtime (min.)
- 10 min. (175W)
- Operating Elevation (m)
- Up to 3000m
- Storage Temperature Range
- +5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
- Full Load Runtime (min.)
- 2 min. (350W)
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- UPS Certification Details
- UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS A; FCC Part 68 Approved (#5WSWP01B005); Industry Canada Approved (#3449A-005, REN0.1B); RETIE (Colombia)
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- UPS Certifications
- Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
- Output Voltage Regulation (Battery Mode)
- 120V (±10%)
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Overvoltage Correction
- Input voltages between 128 and 145 are reduced by 15%
- AC Mode Efficiency Rating (100% Load)
- >95%
- Battery Recharge Rate (Included Batteries)
- 8 hours (10% to 90%)
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- UPS AC Suppression Response Time
- Instantaneous
- Switches
- Power off/on switch
- UPS Dataline Suppression
- 1 line TEL/DSL or Ethernet
- UPS AC Suppression Joule Rating
- 316
- Relative Humidity
- 0 to 90%, non-condensing
- Network UPS Tools Compatibility
- Yes
- EMI / RFI AC Noise Suppression
- Yes
- Battery Access
- Battery access door
- Grounding Lug
- Includes side-panel grounding lug
- Battery Replacement Description
- Replaceable internal batteries (see manual)
- Audible Alarm
- UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
- High Availability UPS Features
- Battery Independent Restart
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- Communications Interface
- USB (HID enabled)
- Undervoltage Correction
- Input voltages between 89 and 108 are boosted by 18%
- Output Volt Amp Capacity (VA)
- 700
- Communications Cable
- USB interface cable included
- Rated input current (Maximum Load)
- 10A
- Recommended Electrical Service
- 15A 120V
- Input Circuit Breakers
- 10A
- High Voltage Transfer to Battery Power (Setpoint)
- 145
- DC System Voltage (VDC)
- 12
- LED Indicators
- 2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions
- Primary Form Factor
- Desktop
- Nominal Input Voltage(s) Supported
- 120V AC
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Low Voltage Transfer to Battery Power (Setpoint)
- 89
- Output Voltage Regulation (Line Mode)
- 120V (+6%/-12%)
- Operating Elevation (ft.)
- Up to 10,000 ft.
- Hot Swappable
- Yes
- Package Contents
- AVR700U 700 VA Desktop UPS, USB Cable, PowerAlert Software CD, Phone Cable, Instruction Manual with Warranty Information
- Load Capacity
- 700 VA/350 W
- Product Series
- AVR
- Modem (RJ-11)
- Yes
- Dataline Protection
- RJ-11
- Software Included
- PowerAlert Software
- Form Factor
- Desktop
- USB
- Yes
- Product Certifications
- RETIE (Colombia); CSA (Canada); NOM (Mexico); UL 1778
- UPS Applications
- Home/Office Desktop; Retail/Point of Sale; Hospitality
- Grounding Details
- Includes side-panel grounding lug
- Output Capacity (Watts)
- 350
- Product Compliance
- FCC Part 15 Class A (USA)
- Package Includes
- AVR700U 700VA 350W 120V Line-Interactive UPS with 8 Outlets;USB cable;Owner's manual
- Output Capacity (VA)
- 700
- Transfer Time - Minimum
- 6 msec
- Frequency
- 50/60 Hz
- Visible Indicator Light Conditions
- Battery Low, Fault, Overload, Power Status, Replace Battery
- Number of Outlets - Surge Only
- 4
- Plug Configuration
- 5-15P
- Receptacle Configuration
- 5-15R
- Input Current - Maximum
- 10 A
- Audible Alarm Conditions
- Low Battery, Overload, Replace Battery
- Battery Recharge Time
- 8 hr
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Output Ports Included
- USB
- Manufacturer Warranty
- 3 yr Limited
- Replacement Battery Part Number
- RBC51
- Power Rating - Real
- 350 W
- Number of Outlets - UPS
- 4
- Run Time - Full Load
- 2 min
- External Battery Compatible
- Not External Battery Pack Compatible
- Power Rating - Apparent
- 700 VA
- Battery Chemistry
- Valve Regulated Lead Acid
- Surge Suppression Rating
- 316 J
- Operating Temperature - Maximum
- 104 Degrees F
- Transfer Time - Maximum
- 10 msec
- Operating Temperature - Minimum
- 32 Degrees F
- Includes Battery
- Battery Included
- Data Line Protection
- Includes Data Line Surge Protection
