Surge Protection Device, 600V, 3 Poles
Mfr # ASISPV600-V-CD-S
Zoro # G112120297
Key Features
Specifications
Product Information
- MFR #
- ASISPV600-V-CD-S
- Zoro #
- G112120297
- UPC #
- 810009764793
- Country of Origin
- China
Dimensions
- Length
- 3 in
- Width
- 1 in
Details
- Item
- Surge Protection Device
- Mounting Style
- DIN Rail
- Voltage
- 600V
- Number of Poles
- 3
- Short Circuit Current Rating
- 200kA
- Includes
- SPD
Description
The ASISPV600-V-CD-S is a 3 pole, 3 wire, 600 Vdc DIN rail mountable modular SPD based on MOV technology, providing advanced surge protection for photovoltaic applications. The device is UL 1449 4th Edition rated Type 4 for use in Type 1, 2 and 3 applications and KEMA certified with a MCOV rating of 700 Vdc. The SPD is factory tested for a SCCR Rating of 200 kA. Remote contact is standard making status monitoring easy. The SPD base is designed to be mounted on 35 mm DIN rail while plugs have easy to read visual indication and are easily replaceable. Replacement plug ASIMSP275 can be purchased separately. Voltage specific keying is on all modules to make it easy to know the plug is assembled to the correct base.
- • 600 V DC
- • Pluggable
- • Din Rail Mount
