This item is Discontinued.

Autonics 36x72mm Multi-Panel Meter AC Amps MT4Y-AA-4N

36x72mm Multi-Panel Meter AC Amps (Discontinued)

  • Mfr # MT4Y-AA-4N
  • Zoro # G4246426
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
MT4Y-AA-4N
Zoro #
G4246426
UPC #
-
Country of Origin
Korea, Republic of

Dimensions

Manufacturers Warranty Length
3 yr
Depth
3.3 in
Cutout Height
1 7/8 in
Digit Height - Maximum
0.559 in
Cutout Width
3 25/32 in
Overall Height
0.56 in
Overall Depth
3.3 in

Details

Item
Digital Panel Meter
Type
AC Current
Input Range
0 to 5AAC
Accuracy
+/-0.3% of Reading +/- 3 Digit
Display Span
-1999 ~ 9999
Display Digits
4
Power Required
100 - 240 V AC 50/60hz
Mounting
Bracket
Output
Indicator
Style
MT4Y Series
Use With
External 5A AC Current Transformer
Display
Red LED Display
Fits
72x36mm
Footnotes
3, 9
Includes
Mounting Brackets
Connector Type
Screw Terminal
Excitation
No
NEMA Rating
NEMA 4X (Front Panel Only)
True RMS
Yes
Interface
RS-485
Panel Meter Type
Digital Multi-Panel Meter
(hidden) product type builder
AUTONICS MT4Y-AA-4N
Standards
CE, EAC, RoHS
Series
MT4Y
Frequency Display - Maximum
9,999 Hz
Includes Mounting Hardware
Included
AC Magnitude Calculation
Average, True RMS
Display Span - Minimum
-1,999
Parameters Measured
AC Voltage
Terminal Connection Type
Screw Clamp
Number of Display Digits
4
Product Type
Digital Panel Meter
AC Voltage Input - Minimum
100 V AC
Frequency Display - Minimum
0.1 Hz
Digital Display Screen Type
LED
Digital Display Screen Color
Red
AC Voltage Input - Maximum
240 V AC
NEMA Enclosure Rating
4X
Display Span - Maximum
9,999

Description

Digital Panel Meter, AC Current, Input Range 0 to 5AAC, Accuracy +/-0.3 Percent of Reading +/- 3 Digit, Display Span -1999 ~ 9999, Display Digits 4, Red LED Display Display, True RMS Yes, No Excitation, Use With External 5A AC Current Transformer, Fits 72x36mm, Connector Type Screw Terminal, Power Required 100 - 240 V AC 50/60hz, RS-485 Interface, Output Indicator, NEMA 4X Front Panel NEMA Rating, Depth 3.3 in, Mounting Bracket, Style MT4Y Series, Includes Mounting Brackets
