  6. Lathe, 120V AC Volts, 1 hp HP, Single Phase 22 in Distance Between Centers
No Product Image Available

Lathe, 120V AC Volts, 1 hp HP, Single Phase 22 in Distance Between Centers

  • Mfr # 1228216

  • Zoro # G014811040

product price:  $10,703.99
/ea
Additional $295.00 delivery surcharge applies per item.
See details

Key Features

Phase
Single
Voltage
120V AC
Distance Between Centers
22 in
Horsepower
1 hp
Tailstock Taper
MT2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
1228216
Zoro #
G014811040
UPC #
019907766858
Country of Origin
China

Dimensions

Bed Width
5 3/10 in
Table Work Surface - Width
5 3/10 in
Table Work Surface - Depth
22 in

Details

Item
Lathe
Phase
Single
Voltage
120V AC
Distance Between Centers
22 in
Horsepower
1 hp
Tailstock Taper
MT2
Includes
Sheet Metal Stand
Spindle Taper
MT4
Number of Spindle Speeds
Variable
Longitudinal Feed - Maximum
0.008 in/rev
Manufacturer Warranty
1 yr
Swing Over Cross Slide
5 7/10 in
Swing Over Bed
9 3/4 in
Longitudinal Feed - Minimum
0.003 in/rev
Metric Thread - Maximum
3.5 mm
Motor Speed - Maximum
2,250 RPM
Maximum Cross Slide Travel
4 1/2 in
Includes Stand
Stand Included
Spindle Speed - Maximum
2,250 RPM
Threads per Inch - Maximum
56
Operation
Powered
Maximum Cross Travel
4 1/2 in
Spindle Bore
1 1/10 in
Includes Taper Attachment
Taper Attachment Included
Includes Chuck
Chuck Included
Threads per Inch - Minimum
8
Spindle Speed - Minimum
50 RPM
Spindle to Table Distance
8 3/8 in
Tailstock Spindle Travel
2 in
Metric Thread - Minimum
0.4 mm
Spindle Nose Taper
MT4
Swing Measurement
9 3/4 in

Description

Lathe,Single
