High Visibility Industrial Fan, 8 ft. Portable Floor Fan (F-AG2-0801)

  • Mfr # F-AG2-0801
  • Zoro # G8625119
product price:
$
10,754.99
/ea
Additional $440.00 delivery surcharge applies per item.
See details

Key Features

Motor HP
2/3 hp
Wire Guard Finish
Powder Coated
Fan Accessory Style
High Visibility
Application
Variable
Motor Enclosure
Open Drip Proof
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
F-AG2-0801
Zoro #
G8625119
UPC #
-
Country of Origin
United States

Dimensions

Height Adjustment
Fixed
Blade Diameter
96 in
Wheel Dia.
8 in

Details

Motor HP
2/3 hp
Wire Guard Finish
Powder Coated
Fan Accessory Style
High Visibility
Application
Variable
Motor Enclosure
Open Drip Proof
Color
Yellow
Air Flow
32,077
Number of Blades
6
Fan Accessory Color
Yellow
Air Velocity @ 40 Ft.
425 fpm
Number of Conductors
0
Wheeled Base
Mobile
Assembly Required
Yes
Air Velocity @ 10 Ft.
600 fpm
Number of Speeds
Variable
Thermal Protection
Manual Reset
Fan Power Source
Plug-In
Air Velocity @ 60 Ft.
330 fpm
Standards
ETL, UL
Voltage
110V AC to 125V AC
Item
Portable Fan
Phase
Single
Fan Accessory Finish
Powder Coated
Fan Mounting Location
Floor
Sound Level
43 dBA
Blade Material
Aluminum
Amps
12 A
NEMA Plug Configuration
5-15P
Blade Material - Fans
Steel
Oscillating
No
Hz
60/50 Hz
Air Velocity @ 80 Ft.
290 fpm
Max. Ambient Temp.
122 Degrees F
Guard Material
Steel
Fan Blade Color
Gray
Fan Housing Material
Steel
Motor Insulation
F
Oscillation
Non-Oscillating
Wheel Material
Rubber
Battery Operated - Fans
No
Environmental Applications
Industrial
Assembled
No
Speed Controllable - Fans
Yes
RPM
180 RPM
Bearing Type
Ball
Drive Type
Direct Drive
Airflow
32,077 cfm
Base Type
Cradle
High-Visibility
Yes
Bearing Protection
Double-Sealed
Fan Shape
Drum

Description

The BIG ASS FANS F-AG2-0801 High Visibility Industrial Fan is a portable, floor-mounted cooling fan with a 96-inch (8-foot) diameter and direct-drive motor. Constructed with a steel housing and aluminum blades, it provides high airflow performance for industrial spaces. The fan operates on 110–125V AC power with variable speed control and a sound level of 43 dBA. It includes rubber wheels for mobility and features a powder-coated yellow finish for visibility in work environments.

Key Features:

  • Fan Type: Portable high-visibility industrial fan
  • Blade Diameter: 96 in (8 ft)
  • Airflow: 32,077 cfm
  • Power Source: Plug-in, 110–125V AC, 50/60 Hz
  • Motor Power: 2/3 hp, direct drive, open dripproof enclosure
  • Speed Control: Variable speed operation
  • Sound Level: 43 dBA
  • Housing and Blade Material: Steel housing with aluminum blades
  • Mobility: Wheeled base with 8 in rubber wheels
  • Thermal Protection: Manual reset
  • Standards: UL and ETL listed
