Shop BISON GEAR & ENGINEERING

AC Gearmotor, 128 in-lb Max. Torque, 47 RPM Nameplate RPM, 230V AC Voltage, 3 Phase

  • Mfr # 017-261-0037

  • Zoro # G0287332

product price:
$
1,197.99
/ea
Free Shipping & Returns

Key Features

Gearmotor Voltage
230V AC
Gearmotor Phase
3
Gearmotor Type
AC Gearmotor
Max. Torque
128 in-lb
Gearmotor Shaft Type
Single
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
017-261-0037
Zoro #
G0287332
UPC #
845171006433
Country of Origin
United States
Item
AC Gearmotor
Gearmotor Voltage
230V AC
Gearmotor Phase
3
Gearmotor Type
AC Gearmotor
Max. Torque
128 in-lb
Gearmotor Shaft Type
Single
Gearmotor Shaft Orientation
Parallel
Nameplate RPM
47 RPM
Gearmotor Enclosure
Totally Enclosed Nonventilated
Gearmotor Rotation
CW/CCW
Gearmotor Brake Type
None
Gearmotor Mounting Position
All Angle
Full Load Amps
0.5 A
Standards
UL Listed
Input HP
1/8 hp
Reversible Shaft Output
Yes
Starting Torque
715 in-lb
Gear Case Material
304 Stainless Steel
Enclosure
TENV
Application
Washdown
Rotation
CW/CCW
Insulation Class
F
Housing
304 Stainless Steel
Finish
Unpainted
Shaft
Single
Bearings
Sealed Ball
Includes
2m Straight Connector Power Cord
RPM @ 50 Hz
31 RPM
Motor Type
3-Phase
Gear Ratio
37:1
Phase
Three
Thermal Protection
None
Max. Ambient Temp.
40 Degrees C
Overhung Load
250 lb
RPM Range
31 to 50
No Load RPM
50 RPM
Seals
Triple Lip Cartridge Seal With Stainless Slinger
Mounting
All Position
Voltage
230
Lubrication
Food Grade Grease
Shaft Orientation
Parallel
Gears
Steel
Gear Material
Steel
Gear Type
Right-Angle
Housing Material
304 Stainless Steel
Number of Output Shafts
1
Mount Type
Any Position
Inverter Rated
Yes
Inverter Rating
37:1
Motor Enclosure
Totally Enclosed Nonventilated
No Load Speed
50 RPM
Mounting Orientation
Any Angle
Input Horsepower
0.125 hp
Motor Insulation Class
F
Overhung Load Capacity
250 lb
Housing Material Finish
Unpainted
Maximum Output Speed
45 RPM
Seal Type
Triple Lip Cartridge Seal With Stainless Slinger
Maximum Torque
128 in-lb
Bearing Type
Sealed Ball
Brake Type
None
Operating Voltage
230V AC
Keyway Type
Rounded
Nameplate Speed
47 RPM
Full Load Current
0.5 A
Shaft Material Grade
Type 304
Maximum Ambient Temperature
104 Degrees F

Description

AC Gearmotor, Number of Output Shafts 1, Motor Type 3-Phase, Motor Enclosure Totally Enclosed Nonventilated, Nameplate Speed 47 RPM, Maximum Torque 136 in-lb, Overhung Load Capacity 250 lb, Rotation CW/CCW, Output Shaft Height 2.5 in, Mounting Orientation Any Angle, Operating Voltage 230V AC, Inverter Rated Yes, Gear Ratio 36.5:1, Brake Type None, Shaft Orientation Parallel, Shaft Material Grade Type 304, Motor Insulation Class F, Application Washdown
