Rigid Plate Caster, PU, 6", 1100 lb.

  • Mfr # BHF-ALTH 150K-16

  • Zoro # G0895373


product price:  $269.99
/ea
Free Shipping & Returns

Key Features

Tread Color
Light Brown
Number of Wheels
1
Extended Lead
No
Tread
Standard
Mounting Bolt Dia.
1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
BHF-ALTH 150K-16
Zoro #
G0895373
UPC #
-
Country of Origin
Germany

Dimensions

Mounting Bolt Dia.
1/2 in
Overall Height
9-1/2 in
Wheel Width
2 in
Wheel Dia.
6 in
Mounting Plate Size
4-1/2 in x 6-1/4 in
Mounting Plate Thickness
0.315 in

Details

Item
Rigid Caster
Tread Color
Light Brown
Number of Wheels
1
Extended Lead
No
Tread
Standard
Load Capacity
680 lb
Replacement Wheel
Mfr. No. ALTH 150/20K
Caster Sub-Type
Rigid
Caster Mounting Type
Plate
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Frame Finish
Zinc Plated
Inside Bolt Hole Spacing
2-7/16 in x 4-15/16 in
Application
Food Service, Food Processing, Drug Manufacturing, Retail, Industrial, Commercial, Automotive, Clean Room, Aerospace
Core Color
Silver
Non-Marking
Yes
Caster Frame Material
Steel
Standards
RoHS, ICWM
Caster Brake Type
No Brake Included
Caster Brake Included
No
Load Rating Range
Medium Duty
ESD Conductive
No
Number of Mounting Holes
4
Series
BHF Series
Tread Shape
Standard
System of Measurement
Inch
Resistant To
High Chemical Resistance To Many Aggressive Substances
Max. Spring Deflection
1 in
Wheel Core Material
Aluminum
Includes Thread Guards
No
Wheel/Tread Material
Extrathane Polyurethane
Wheel Bearing Type
Precision Ball
Wheel Hardness Rating
92 Shore A
Maximum Compression Force
1255 lb
Operating Temperature Range
-15 Degrees To 160 Degrees F

Description

Rigid
