Shop All Air Nailers & Staplers
Bostitch

Air Nailer, 33 deg. Collation Angle

product price: $305.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Head Style Clipped
  • Collation Angle 30 Degrees
  • Collation angle 30 Degrees
  • Collation Type Paper
  • Fastener Range 2 in to 3-1/4 in
See all product information

Product Information

Dimensions

Shank Dia. 0.113 in to 0.131 in
Width 5 3/4 in
Height 12 3/4 in
Length 19 3/4 in
Depth Control Yes
For Nail Shank Diameter 0.113 in to 0.131 in
Overall Height 12 3/4 in
Min. Hose Size 1/4 in
Overall Width 5 3/4 in
For Nail Length Range 2 in to 3 1/4 in
Overall Length 19 3/4 in

Details

Item Nail Gun
Head Style Clipped
Collation Angle 30 Degrees
Collation angle 30 Degrees
Collation Type Paper
Fastener Range 2 in to 3-1/4 in
Magazine Capacity 90
Tool Weight 7.8 lb
Features Low Profile Design, Tool Free Adjustability
Exhaust Fixed
Air Inlet 3/8 in NPT
Housing Material Magnesium
Style Paper Tape
Color Yellow
Max. Pressure 120 psi
Tip Nonmarring
Required Pressure 70 to 120 psi
Includes 3/8 in Male Fitting
For Use With 30 Degrees Paper Tape Nails
Firing Mode Combination
CFM per Shot 6.4
Handle Type Pistol Grip
Power Source Air Powered
Air Pressure Range 70 to 120 psi
Exhaust Location Top
Standards ANSI
Max. Air Pressure 120 psi
Duty Rating Industrial Duty
Nail Capacity 90
Nail Gun Type Framing
Min. Air Pressure 70 psi
Air Consumption 6.4 cfm
Built-In Light No
Air Pressure 70 psi
For Nail Head Style Various
Collation Style Strip

Description

Nail Gun, Power Source Air Powered, Air Consumption 6.4 cfm, Air Inlet 3/8 in NPT, Air Pressure 70 psi, Air Pressure Range 70 to 120 psi, Max. Air Pressure 120 psi, Min. Air Pressure 70 psi, Min. Hose Size 1/4 in, Exhaust Location Top, Tool Brand Bostitch, Firing Mode Combination, Tip Nonmarring, Depth Control Yes, Collation Style Strip, Collation Type Paper, Collation Angle 30 Degrees , For Nail Head Style Various, For Nail Length Range 2 in to 3 1/4 in
