Brooks Flowmeter, Air, 10 to 100 LPM, Buna-n Seal 2510A2A18BNBN

Flowmeter, Air, 10 to 100 LPM, Buna-n Seal (Discontinued)

  • Mfr # 2510A2A18BNBN
  • Zoro # G4534047
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2510A2A18BNBN
Zoro #
G4534047
UPC #
-
Country of Origin
United States

Dimensions

For Pipe Size
1/8 to 1 in
Connection Size
1/8 in
Connection Size (In.)
1/8 FNPT
Width
1 in
Height (In.)
4
Depth
1 1/8 in
Center-Center Insert Size
1 5/8 in
Height
4 in
Width (In.)
1"
Center-Center Fitting Size
3 in
Manufacturers Warranty Length
1 yr
Overall Height
4 in
Manufacturer Warranty Length
1 yr
Overall Width
1 in
Overall Length
1.1 in

Details

Item
Mechanical Flowmeter
Housing Material
Acrylic
Type
Variable Area
Flow Material
Air
Connection Type
FNPT
Max. Pressure
100 psi
Max. Viscosity
79.8 SUS
Wetted Materials
Brass, Buna, Clear Acrylic, Stainless Steel
Flow Range
11 to 100 lpm
Fluid Temp. Range
40 Degrees to 150 Degrees F
Fitting
Brass
Includes
Flowmeter Only
Flow Range (LPM)
10 to 100
O-Ring
Buna
Max. Temp. (F)
150
Insert
10-32 Threaded Brass
Accuracy (%)
+/-5
Max. Pressure (PSI)
100
Application
For Measuring Liquid or Gas Flows in Air Sampling Equipment, Chromatography Systems, Desalinization Equipment, Gas Analyzers, Medical Systems, Photo Equipment, Water Treatment and Distribution and in Aquaculture System
Flow Range @ LPM of Air
10 to 100
Seal Material
Buna-N
Standards
International Calibration Certificate (ICC), Pressure Equipment Directive (97/23/EC), RoHS
Display Type
Scale
Output Type
Scaled Pulse
Product Type
Machined Flow Meter
Compatible Flow Material
Air
Accuracy
5%
Flowmeter Type
Variable Area
Includes Pressure Gauge
No
Viscosity - Maximum
79.8 SUS
Operating Pressure - Maximum
100 psig
Includes Totalizer
No
Unit Of Measure
Liters
Media Temperature - Minimum
40 Degrees F
O-Ring Material
Buna-N
Flow Rate - Minimum
10 lpm
Mounting Orientation
Vertical
Wetted Material
Acrylic, Brass, Buna-N, Stainless Steel
Includes Flow Rate Adjustment Knob
No
Flow Rate - Maximum
100 lpm
Media Temperature - Maximum
150 Degrees F

Description

Mechanical Flowmeter, Product Type Machined Flow Meter, Flowmeter Type Variable Area, Accuracy 5 Percent, Connection Size 1/8 in, Connection Type FNPT, Compatible Flow Material Air, Media Temperature - Maximum 150 Degrees F, Media Temperature - Minimum 40 Degrees F, Viscosity - Maximum 79.8 SUS, Voltage - Maximum Not Applicable, Housing Material Acrylic, Rotor Material Not Applicable, O-Ring Material Buna-N, Seal Material Buna-N, Shaft Material Not Applicable

Restrictions

This is a restricted item in CA, LA, MD, VT. It cannot be used for potable water applications.
