This item is Discontinued.

Brooks Meter, Air, 10-100 Scfm 2540A5A52PS

Meter, Air, 10-100 Scfm (Discontinued)

  • Mfr # 2540A5A52PS
  • Zoro # G2623022
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2540A5A52PS
Zoro #
G2623022
UPC #
-
Country of Origin
United States

Dimensions

For Pipe Size
1/8 to 1 in
Connection Size
1 in
Depth
2 in
Center-Center Insert Size
4 1/2 in
Width
1 3/4 in
Height (In.)
13-1/2
Connection Size (In.)
1 FNPT
Height
13 1/2 in
Width (In.)
1-3/4"
Overall Length
4.8 in
Overall Height
10.9 in
Overall Width
1.8 in

Details

Item
Mechanical Flowmeter
Type
Variable Area
Housing Material
Acrylic
Flow Material
Air
Connection Type
FNPT
Max. Pressure
100 psi
Wetted Materials
316 Stainless Steel, Clear Acrylic, PVC
Max. Viscosity
79.8 SUS
Flow Range
10 to 100 scfm
Fluid Temp. Range
40 Degrees to 150 Degrees F
Fitting
PVC
Flow Range @ SCFM
10 to 100
Accuracy (%)
+/-2
Insert
10-32 Threaded Brass
Seal Material
Buna-N
Application
For Measuring Liquid or Gas Flows in Air Sampling Equipment, Chromatography Systems, Desalinization Equipment, Gas Analyzers, Medical Systems, Photo Equipment, Water Treatment and Distribution and in Aquaculture System
Flow Range @ SCFM of Air
10 to 100
O-Ring
Nitrile
Max. Temp. (F)
150
Max. Pressure (PSI)
100
Output Type
Scaled Pulse
Standards
International Calibration Certificate (ICC), Pressure Equipment Directive (97/23/EC), RoHS
Product Type
Machined Flow Meter
Viscosity - Maximum
79.8 SUS
Compatible Flow Material
Air
Accuracy
2%
O-Ring Material
Buna-N
Unit Of Measure
Gallons, Liters
Flow Rate - Minimum
10 scfm
Media Temperature - Minimum
40 Degrees F
Wetted Material
316 Stainless Steel, Acrylic, PVC
Mounting Orientation
Vertical
Flow Rate - Maximum
100 scfm
Flowmeter Type
Variable Area
Operating Pressure - Maximum
100 psig
Media Temperature - Maximum
150 Degrees F

Description

Mechanical Flowmeter, Product Type Machined Flow Meter, Flowmeter Type Variable Area, Accuracy 2 Percent, Connection Size 1 in, Connection Type FNPT, Compatible Flow Material Air, Media Temperature - Maximum 150 Degrees F, Media Temperature - Minimum 40 Degrees F, Viscosity - Maximum 79.8 SUS, Housing Material Acrylic, O-Ring Material Buna-N, Seal Material Buna-N, Shaft Material -, Wetted Material 316 Stainless Steel, Acrylic, PVC

Restrictions

This is a restricted item in CA, LA, MD, VT. It cannot be used for potable water applications.
