Shop BRYANT

Straight Blade Plug, 5-15P, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # BRY5266NP

  • Zoro # G4438729

product price:  $14.25
/ea

Key Features

NEMA Plug Configuration
5-15P
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
BRY5266NP
Zoro #
G4438729
UPC #
30781786005878
Country of Origin
China

Dimensions

For Maximum Cable Diameter
0.655 in
For Minimum Cable Diameter
0.30 in
Cord Size
0.245 in to 0.655 in
Minimum Wire Size
14 AWG
Outside Diameter
1.52 in
Body Length
2.18 in
Maximum Wire Size
12 AWG
Face Diameter
1.38 in
Height
1.38 in
Width
1.52 in
Display Size
Standard Sized
Length
2.18 in
Wire Size
#14 AWG to #12 AWG

Details

Item
Straight Blade Plug
NEMA Plug Configuration
5-15P
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Grounding
Grounded
Housing Color
Black, White
IP Rating
Not Rated
Standards
CSA, UL
Resistance Properties
Chemical Resistant, Impact Resistant
Number of Wires
3
Grade - Plugs and Receptacles
Industrial
Special Features
Ergonomic, Fluted Body Design
Grade
Industrial
Phase - Plugs and Receptacles
1
NEMA Plug Configuration - Plugs and Receptacles
5-15P
Antimicrobial
No
Corrosion Resistant
No
HP
0.5
Voltage
125VAC
Material
Nylon
Housing Material
Composite
Compatible with Series
Triple Gripper(R)
Market
Commercial, Industrial
For Location
Indoor
For Environment
Dry
Insulation Material
Nylon
Polarized
Yes
Horsepower Rating
1/2 hp
Cord Type
All Portable
Application
Extra Heavy Duty Industrial Grade; Industrial
Wire Gauge
#14 AWG to #12 AWG
Mounting Hardware
Cord Mounted
Style
Extra Heavy Duty
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Wattage
1875
Series
Triple Gripper(R)
Material - Mounting Hardware
Cord Mounted
Shrouded
Yes
Power Indicating Light
No

Description

Straight Blade Plug, Connection Orientation Straight, Current Rating 15 A, Grounding Grounded, Horsepower Rating 1/2 hp, Housing Color Black, White, IP Rating Not Rated, NEMA Plug Configuration 5-15P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Chemical Resistant, Impact Resistant, Voltage Rating 125V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, Face Diameter 1.38 in, For Maximum Cable Diameter 0.655 in
