  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Bryant Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded BRY5262GRY - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # BRY5262GRY

  • Zoro # G4819276

product price: $8.79
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BRY5262GRY
Zoro #
G4819276
UPC #
-
Country of Origin
China

Dimensions

Minimum Wire Size
14 AWG
Mount Hole Center-to-Center Height
3.3 in
Face Plate Width
1.5 in
Maximum Wire Size
12 AWG
Overall Depth
1.2 in
Display Size
Standard Sized Product
Wire Size
#14 AWG to #12 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Gray
Mount Type
Flush
Standards
CSA Certified, Federal Specification W-C-59, NEMA WD-1 and WD-6, UL 498, UL Listed
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Weather Resistant - Plugs and Receptacles
No
Material
Nylon
Surge Suppression
No
Special Features
Isolated Ground
Corrosion Resistant
No
Voltage
125VAC
Power Indicator
No
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Mounting Type
Flush
Wiring Method - Plugs and Receptacles
Back and Side
Tamper Resistant
No
Weather Resistant
No
Mounting Type - Plugs and Receptacles
Flush
Sub-Category
Duplex Receptacles
Outlet Type - Plugs and Receptacles
Standard Duplex
Application Environment
Harsh and Heavy Use Industrial
Number of Gangs
1
Outlet Type
Duplex
HP
1/2 hp
Includes Mounting Hardware
Yes
Contact Material
Brass
GFCI
No
For Location
Indoor
Connection Orientation
Straight
Grade
Federal Specification
Housing Material
Nylon
Polarized
Yes
Surge Protection
No
Market
Commercial, Industrial
Cover Type
No Cover
Includes
Mounting Hardware
Horsepower Rating
1/2 hp
AFCI
No
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Style
Finder Groove Face
Material - Mounting Hardware
Screw Mounting
Wattage
1875
Nema Rating
5-15R
Application
Extra Heavy Duty Industrial Specification Grade
Series
Extra Heavy Duty

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Housing Color Gray, Housing Material Nylon, Mount Type Flush, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Standards CSA Certified, Federal Specification W-C-59, NEMA WD-1 and WD-6, UL 498, UL Listed, Voltage Rating 125V AC, Wire Connection Type Screw Terminals
