Shop BRYANT

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # 21254GY

  • Zoro # G4819635

product price:
$
27.49
/ea

Key Features

Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
21254GY
Zoro #
G4819635
UPC #
781786336605
Country of Origin
United States

Dimensions

Height
0.92 in
Width
4.30 in
Face Plate Height
4.3 in
Face Plate Width
4.3 in
Mount Hole Center-to-Center Width
3.4 in
Overall Depth
0.9 in
Minimum Wire Size
14 AWG
Maximum Wire Size
12 AWG
Mount Hole Center-to-Center Height
3.4 in
Wire Size
#14 AWG to #12 AWG
Display Size
Standard Sized Product
Length
4.3 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Gray
Mount Type
Flush
Standards
CSA Certified, UL Listed
Resistance Properties
Corrosion Resistant
Flange Type
Non-Flanged
Outlet Type
Quad
Application Environment
Commercial
NEMA Configuration
5-20
Surge Suppression
No
Mounting Type
Flush
HP
1 hp
Corrosion Resistant
Yes
Mounting Type - Plugs and Receptacles
Flush
Wiring Method - Plugs and Receptacles
Back and Side
Sub-Category
Quad Receptacles
Voltage
125VAC
Material
Nylon
Number of Gangs
1
Special Features
Corrosion resistant
Weather Resistant - Plugs and Receptacles
No
Tamper Resistant
No
Weather Resistant
No
Outlet Type - Plugs and Receptacles
Quad
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Power Indicator
No
Includes
Mounting Hardware
Horsepower Rating
1 hp
Housing Material
Composite
Contact Material
Brass
Cover Type
No Cover
For Location
Indoor
AFCI
No
GFCI
No
Number of Outlets
4
Market
Commercial, Industrial
Polarized
Yes
Grade
General Use
Includes Mounting Hardware
Yes
Surge Protection
No
Connection Orientation
Straight
Application
Commercial/Industrial
Material - Mounting Hardware
Screw Mounting
Wattage
2500
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Style
Smooth Face
Nema Rating
5-20R
IP Rating
IP20
Number of Wall Plates Included
0

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Gray, Housing Material Composite, Mount Type Flush, NEMA Enclosure Rating Not Applicable, NEMA Receptacle Configuration 5-20R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Quad, Resistance Properties Corrosion Resistant, Standards CSA Certified, UL Listed
