  11. Straight Blade Receptacle, 6-15R, 15 A, 250V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Bryant Straight Blade Receptacle, 6-15R, 15 A, 250V AC, 2 Pole, 3 Wire, Flush Mount, Grounded 5679 - main

Straight Blade Receptacle, 6-15R, 15 A, 250V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # 5679

  • Zoro # G4571360

product price: $24.00
/ea

Key Features

Receptacle Type
Single
NEMA Receptacle Configuration
6-15R
Current Rating
15 A
Voltage Rating
250V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
5679
Zoro #
G4571360
UPC #
781786663909
Country of Origin
United States

Dimensions

Face Diameter
1.5 in
Mount Hole Center-to-Center Height
2 in
Overall Depth
1.5 in
Display Size
Standard Sized Product

Details

Item
Straight Blade Receptacle
Receptacle Type
Single
NEMA Receptacle Configuration
6-15R
Current Rating
15 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Grounding
Grounded
Housing Color
White
Mount Type
Flush
Standards
CSA Certified, UL Listed
Resistance Properties
Impact Resistant
Flange Type
Flanged
Weather Resistant
No
NEMA Receptacle Configuration - Plugs and Receptacles
6-15R
Corrosion Resistant
No
Wiring Method
Back
Material
Nylon
Voltage
250VAC
Outlet Type - Plugs and Receptacles
Inlet
Number of Gangs
1
Power Indicator
No
Mounting Type - Plugs and Receptacles
Panel
Surge Suppression
No
Mounting Type
Panel
Wiring Method - Plugs and Receptacles
Back
HP
1 1/2 hp
Application Environment
Industrial
Sub-Category
Flanged Receptacles
Outlet Type
Inlet
Tamper Resistant
No
Weather Resistant - Plugs and Receptacles
No
For Location
Indoor
Connection Orientation
Straight
Surge Protection
No
AFCI
No
Polarized
Yes
Cover Type
No Cover
Market
Commercial, Industrial
Horsepower Rating
1 1/2 hp
GFCI
No
Housing Material
Nylon
Grade
General Use
Nema Rating
6-15R
Series
Heavy Duty
Style
Smooth Face
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Application
Commercial/Industrial

Description

Flanged Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Housing Color White, Housing Material Nylon, Mount Type Flush, NEMA Receptacle Configuration 6-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Single, Resistance Properties Impact Resistant, Standards CSA Certified, UL Listed, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Method Back, AFCI No
