  11. Mechanical Lug, 2/0 AWG Max, 1 Conductor, 1 Hole, 1/2 in Stud, Copper
Burndy Mechanical Lug, 2/0 AWG Max, 1 Conductor, 1 Hole, 1/2 in Stud, Copper QDA26 - main

Mechanical Lug, 2/0 AWG Max, 1 Conductor, 1 Hole, 1/2 in Stud, Copper

  • Mfr # QDA26

  • Zoro # G4665577

product price: $92.39
/ea
Free Shipping & Returns

Key Features

No. of Conductors
1
Min. Conductor Size
1/0 AWG Stranded
Max. Conductor Size
2/0 AWG Stranded
Number of Holes
1
Stud Size
1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
QDA26
Zoro #
G4665577
UPC #
781810553909
Country of Origin
Mexico

Dimensions

Min. Conductor Size
1/0 AWG Stranded
Max. Conductor Size
2/0 AWG Stranded
Stud Size
1/2 in
Length
2.5 in
Width
1.19 in
Length (Straight Wireway)
2.5 in
For Stud Size
1/2 in
Overall Width
1.19 in
Tongue Width
1.25 in
Hole Diameter
0.56 in
For Stranded Copper Wire Size - Maximum
2/0 AWG
Overall Length
2.5 in
Tongue Thickness
0.31 in
For Stranded Copper Wire Size - Minimum
1/0 AWG
Overall Depth
1 1/4 in
Conductor Size
1/0-2/0 AWG
Dimension - Width inch
1.25 in
Dimension - Pad Width inch
1.25 in
Dimension - Hole Size fraction
45185
Dimension - Hole Size mm
14 mm
Dimension - Length Overall inch
2.50 in
Dimension - L Length Overall mm
64 mm
Conductor - Copper Str Size Range
1/0 -2/0 AWG
Dimension - Stud Size inch
44928
Dimension - Height fraction
42372
Conductor - Copper Str Size
1/0 ;2/0 AWG
Dimension - Width mm
32 mm
Dimension - Hole Size inch
0.56 in
Dimension - Cross Flats inch
0.69 in
Conductor - Copper Str Navy Size Range
100 (61) Navy-125 (61) Navy
Conductor - Copper Str Navy Size
100 (61) Navy;125 (61) Navy
Dimension - Height inch
1.19 in
Dimension - Bolt Size fraction
1 to 2
For Maximum Wire Size
2/0 AWG
For Minimum Wire Size
1/0 AWG

Details

Item
Mechanical Lug
No. of Conductors
1
Number of Holes
1
Material
Copper
Standards
UL Listed
Body Material
Copper
Head Style
Hex
Contact Finish
Unplated
Maximum Operating Temperature
194 Degrees F
Maximum Voltage
600 V
Torque
180 in-lb
Number of Conductors
1
Special Features
Low Contact Resistance When Gripped Between Two Contact Nuts, One Wrench Installation
Compatible with Product Type
Copper Cable
For Conductor Material
Copper
Number of Terminations
1
Type
Bolted Lugs & Terminals
Plating Type
Unplated
Physical Attribute - Number of Holes
1
Plated
N
Industry Standard(s)
UL468A-468B
Physical Attribute - Screw Type
Hexagonal Bolt
Physical Attribute - Number of Screws
1
UL Listed
Yes
Application
For Joining A Wide Range Of Copper Cable To Equipment Studs
Installation Torque Recommended in-lb
180 LBS/in
Certification - CSA Approved
No
Trade Name
QIKLUGâ„¢
Conductor Type
CU C Str-SizeCU C Str Navy-Size
Connector Type
Single Clamp

Description

Mechanical Connector, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 1/0 AWG, For Stranded Copper Wire Size - Maximum 2/0 AWG, For Stud Size 1/2 in, Head Style Hex, Number of Holes 1, Hole Diameter 0.56 in, Hole Spacing Not Applicable, Body Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 1, Number of Terminations 1, Tongue Length Not Applicable, Tongue Width 1.25 in, Tongue Thickness 0.31 in
