Mechanical Lug, 250 kcmil Max, 2 Conductor, 5/8 in Stud, Aluminum
Mfr # AMS250
Zoro # G4695591
product price:Â
$
27.99
/ea
Key Features
Connector Type
Splice/Reducer
For Conductor Material
Aluminum, Copper
For Minimum Wire Size
6 AWG
For Maximum Wire Size
250 kcmil
Number of Conductors
2
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- AMS250
- Zoro #
- G4695591
- UPC #
- 781810554579
- Country of Origin
- Mexico
Dimensions
- For Minimum Wire Size
- 6 AWG
- For Maximum Wire Size
- 250 kcmil
- For Stud Size
- 5/8 in
- Min. Conductor Size
- 6 AWG Stranded
- Width
- 1.09 in
- Length
- 4.09 in
- Max. Conductor Size
- 250 kcmil Solid
- Length (Straight Wireway)
- 4.09 in
- Overall Length
- 4.09 in
- For Stranded Copper Wire Size - Maximum
- 250 kcmil
- For Stranded Copper Wire Size - Minimum
- 6 AWG
- Overall Width
- 1.09 in
- Overall Depth
- 1 in
- Conductor Size
- 6 AWG-250 KCMIL
- Dimension - Width mm
- 25 mm
- Dimension - Height fraction
- 11691
- Hex Size
- 45062
- Conductor - Copper Solid Size
- 4 AWG;3 AWG;2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
- Conductor - Copper Str Size Range
- 6 AWG-250 kcmil
- Conductor - Copper Str Size
- 6 AWG;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil
- Conductor - AL Str Size Range
- 6 AWG-4/0 AWG
- Conductor - Copper Solid Size Range
- 4 AWG-4/0 AWG
- Dimension - H1 Height inch
- 1.09 in
- Conductor - AL Str Size
- 6 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
- Dimension - Width fraction
- 1 in
- Dimension - L Length Overall mm
- 104 mm
- Dimension - Width inch
- 1.00 in
- Dimension - Length Overall inch
- 4.09 in
- Wire Rope Length
- 4.09 in
Description
Mechanical Connector, For Conductor Material Aluminum, Copper, For Stranded Copper Wire Size - Minimum 6 AWG, For Stranded Copper Wire Size - Maximum 250 kcmil, For Stud Size 5/8 in, Head Style Hex Socket, Number of Holes Not Applicable, Hole Diameter Not Applicable, Hole Spacing Not Applicable, Body Material Aluminum, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 2, Number of Terminations 4, Tongue Width Not Applicable, Tongue Thickness Not Applicable
