Mechanical Lug, 4 AWG Max, 1 Conductor, 1 Hole, 1/4 in Stud, Copper
Mfr # KA4C
Zoro # G4666103
CAD Available
product price: $6.75
/eaKey Features
CAD Drawing
No. of Conductors
1
Min. Conductor Size
14 AWG Stranded/Solid
Max. Conductor Size
4 AWG Stranded/Solid
Number of Holes
1
Stud Size
1/4 in
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
KA4C
Zoro #
G4666103
UPC #
781810554272
Country of Origin
India
Dimensions
Min. Conductor Size
14 AWG Stranded/Solid
Max. Conductor Size
4 AWG Stranded/Solid
Stud Size
1/4 in
Length
1.11 in
Width
0.77 in
Length (Straight Wireway)
1.11 in
Overall Length
1.11 in
Tongue Thickness
0.11 in
For Stranded Copper Wire Size - Minimum
14 AWG
Hole Diameter
0.28 in
Tongue Width
0.56 in
Overall Width
0.77 in
For Stud Size
1/4 in
Overall Depth
9/16 in
For Stranded Copper Wire Size - Maximum
4 AWG
Conductor Size
14-4 AWG
Dimension - Length Overall inch
1.11 in
Conductor - Copper Str Size
14 AWG;12 AWG;10 AWG;9 AWG;8 AWG;7 AWG;6 AWG;5 AWG;4 AWG
Dimension - B Length inch
0.47 in
Conductor - Copper Str Size Range
14 AWG-4 AWG
Conductor - Copper Solid Size Range
14 AWG-4 AWG
Dimension - B Length fraction
8/17 in
Dimension - Height fraction
44989
Dimension - Pad Width inch
0.54 in
Dimension - N inch
0.25 in
Conductor - Copper Solid Size
14 AWG;13 AWG;12 AWG;11 AWG;10 AWG;9 AWG;8 AWG;7 AWG;6 AWG;5 AWG;4 AWG
Dimension - Bolt Size fraction
2023-01-04
Dimension - Hole Size mm
7 mm
Dimension - Hole Size inch
0.28 in
Dimension - Stud Size inch
44930
Dimension - L Length Overall mm
28 mm
Dimension - Height inch
0.77 in
Dimension - Hole Size fraction
11933
For Minimum Wire Size
14 AWG
For Maximum Wire Size
4 AWG
Description
Mechanical Connector, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 14 AWG, For Stranded Copper Wire Size - Maximum 4 AWG, For Stud Size 1/4 in, Head Style Slotted, Number of Holes 1, Hole Diameter 0.28 in, Hole Spacing Not Applicable, Body Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 1, Number of Terminations 1, Tongue Length Not Applicable, Tongue Width 0.56 in, Tongue Thickness 0.11 in
