Mechanical Lug, 4/0 AWG Max, 1 Conductor, 2 Hole, 3/8 in Stud, Copper

  • Mfr # QA282B

  • Zoro # G4678563

product price:  $103.99
/ea
Free Shipping & Returns

Key Features

Connector Type
Terminal
For Conductor Material
Copper
For Minimum Wire Size
3/0 AWG
For Maximum Wire Size
4/0 AWG
Number of Conductors
1
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
QA282B
Zoro #
G4678563
UPC #
781810553701
Country of Origin
Mexico

Dimensions

For Minimum Wire Size
3/0 AWG
For Maximum Wire Size
4/0 AWG
For Stud Size
3/8 in
Hole Diameter
0.41 in
Tongue Width
1 in
Min. Conductor Size
3/0 AWG Stranded
Max. Conductor Size
4/0 AWG Stranded
Width
1.31 in
Length
3.19 in
Stud Size
3/8 in
Length (Straight Wireway)
3.19 in
Overall Depth
1 in
Tongue Thickness
0.25 in
Tongue Length
2 in
Overall Width
1.31 in
For Stranded Copper Wire Size - Maximum
4/0 AWG
For Stranded Copper Wire Size - Minimum
3/0 AWG
Overall Length
3.19 in
Dimension - Height inch
1.31 in
Dimension - Stud Size inch
44993
Conductor - Copper Str Size Range
3/0 AWG-4/0 AWG
Dimension - Hole Size inch
0.41 in
Conductor - Copper Str Navy Size Range
150 (61) Navy-200 (61) Navy
Conductor - Copper Str Size
3/0 AWG;4/0 AWG
Dimension - Height fraction
1-9/29 in
Dimension - Pad Width inch
1.00 in
Dimension - N inch
0.44 in
Dimension - B Length inch
1.03 in
Dimension - D inch
2.00 in
Conductor - Copper Str Navy Size
150 (61) Navy;200 (61) Navy
Dimension - Length Overall inch
3.19 in
Dimension - Hole Size fraction
13/32
Dimension - L Length Overall mm
81 mm
Dimension - B Length fraction
1-1/33 in
Dimension - F Width Center to Center inch
1.00 in
Dimension - Hole Size mm
10 mm
Wire Rope Length
3.19 in

Details

Item
Mechanical Lug
Connector Type
Terminal
For Conductor Material
Copper
Number of Conductors
1
Number of Terminations
1
Number of Holes
2
Body Material
Copper
Contact Finish
Unplated
Maximum Voltage
600 V
Maximum Operating Temperature
194 Degrees F
Standards
UL Listed
Material
Copper
No. of Conductors
1
Head Style
Hex
Hole Spacing
1 in
Torque
250 in-lb
Compatible with Product Type
Copper Cable
Special Features
Heavy Duty, Joining A Wide Range Of Cable
Type
Bolted Lugs & Terminals
Temperature Rating
194
Application
For Copper Cable
Physical Attribute - Number of Holes
2
Certification - CSA Approved
No
Physical Attribute - Number of Screws
1
Physical Attribute - Screw Type
Hexagonal Bolt
Plated
N
Plating Type
Unplated
UL Listed
Yes
Rating - Minimum Voltage
600
Industry Standard(s)
UL468A-468B
Installation Torque Recommended in-lb
250 LBS/in
Connection Orientation
Compact

Description

Mechanical Connector, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 3/0 AWG, For Stranded Copper Wire Size - Maximum 4/0 AWG, For Stud Size 3/8 in, Head Style Hex Head, Number of Holes 2, Hole Diameter 0.41 in, Hole Spacing 1 in, Body Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 1, Number of Terminations 1, Tongue Length 2 in, Tongue Width 1 in, Tongue Thickness 0.25 in, Connector Type Terminal
