3-Phase Belt Drive Motor, 1/4 HP, 56 Frame, 200-230/460V AC Voltage, 1,140 Nameplate RPM (Discontinued)
- Mfr # H1026
- Zoro # G2513156
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
MFR #
H1026
Zoro #
G2513156
UPC #
-
Country of Origin
Mexico
Dimensions
Shaft Dia.
5/8 in
Overall Length
10 1/16 in
Shaft Length
1 15/16 in
Body Dia.
6 1/2 in
Length Less Shaft
8 1/8 in
Description
Belt Drive Motor, Three Phase, Motor Design 3-Phase, 1/4 HP, Nameplate RPM 1,140, No. of Speeds 1, Voltage 200-230/460V AC, 1.3-1.2/0.60 A Full Load Amps, 56 Frame, Usable @ 208V Yes, Usable @ 200V Yes, 60 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class B, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Nonventilated, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle
