Century

3-Phase Belt Drive Motor, 3/4, 1/3 HP, 56 Frame, 460V AC Voltage, 1,725/1,140 Nameplate RPM

Century 3-Phase Belt Drive Motor,  3/4,  1/3 HP,  56 Frame,  460V AC Voltage,  1,725/1,140 Nameplate RPM H658V1
Tap to zoom
Hover or click to zoom
Feedback Help us improve our product images
$451.94
  • Item: Belt Drive Motor
  • Motor Design: 3-Phase
  • Motor Enclosure Design: Open Dripproof
See full product details
This item ships free.
Total: $451.94

Century #H658V1 Specifications

  • Item: Belt Drive Motor
  • Motor Design: 3-Phase
  • Motor Enclosure Design: Open Dripproof
  • HP: 3/4, 1/3
  • No. of Speeds: 2
  • RPM Range: 1,701-1,800
  • Nameplate RPM: 1,725/1,140
  • Voltage: 460V AC
  • Frame: 56
  • Motor Mounting Type: Cradle Base
  • Shaft Dia.: 5/8 in
  • Motor Thermal Protection: None
  • Motor Service Factor: 1.25
  • Voltage Compatibility: 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 220-230/460V AC, 220/460V AC, 230/460/796V AC, 230/460V AC, 440-460V AC, 460/796V AC, 460V AC
  • Phase: Three
  • Motor Application: HVAC/R
  • Motor Sub Application: Belt Drive Fan/Blower
  • Motor Frame Material: Steel
  • Frame Material: Steel
  • Mounting Stud Pattern: 4 1/8 in x 4 1/8 in
  • Resilient Ring Dia.: 2 1/2 in
  • Standards: CSA, UL Recognized
  • Overall Length: 10 11/16 in
  • Length Less Shaft: 8 13/16 in
  • Footnotes: 26
  • Motor Mounting Position: All Angle
  • Motor Shaft Rotation: CW/CCW
  • Motor Bearings: Ball
  • Shaft Length: 1 7/8 in
  • Duty: Continuous
  • Nominal Efficiency: 66 %
  • Hz: 60
  • Ring to Ring Center: 8 1/4 in
  • Full Load Amps: 1.30/0.82
  • Body Dia.: 6 1/2 in
  • Max. Ambient Temp.: 40 Degrees C
  • Ins. Class: B
  • Motor Shaft Design: Keyed
  • Usable @ 208V: No
  • Extended Thru-Bolts: Yes
  • Usable @ 200V: No
  • Duty Cycle: Continuous
  • Weight: 25 lb
  • Country of Origin (subject to change): Mexico
Feedback Help us improve our product information

Description

Belt Drive Motor, Three Phase, Motor Design 3-Phase, 1/3, 3/4 HP, Nameplate RPM 1,725/1,140, No. of Speeds 2, Voltage 460V AC, 1.30/0.82 Full Load Amps, 56 Frame, Usable @ 208V No, Usable @ 200V No, 60 Hz, Motor Service Factor 1.25, Motor Thermal Protection None, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle, Motor Frame Material Steel
