Three-Phase General Purpose Motor, 1/2 HP, J56 Frame, 575V Voltage, 1,725 Nameplate RPM
Mfr # H940V1
Zoro # G512192085
product price:Â $599.99
/ea
Free Shipping & Returns
Key Features
HP
1/2
Nameplate RPM
1,725
Voltage
575V
Motor Mounting Type
Rigid Base
Full Load Amps
0.70 A
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
MFR #
H940V1
Zoro #
G512192085
UPC #
786674024671
Country of Origin
Mexico
Dimensions
Length Less Shaft
9 1/8 in
Overall Length
11 1/16 in
Shaft Dia.
5/8 in
Shaft Length
1 15/16 in
Frame Size
56
Shaft Diameter
5/8 in
Description
General Purpose Motor, Three-Phase, Open Drip Proof Motor Enclosure Design, 1/2 HP, Nameplate RPM 1,725, Frame J56, Voltage 575V, 60 Hz Hz, Three Phase, Full Load Amps 0.70 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class B, Motor Service Factor 1.25, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, 1725, CSA Certified, UL Listed
