- MFR #
- WWG116.123.AB.1T
- Zoro #
- G3407634
- UPC #
- 611943474225
- Country of Origin
- United States
- Faucet Operation
- Sensor
- Mounting Hole Center to Center
- Single Hole
- Number of Holes
- 1
- Mounting Type
- Deck Mount
- ADA Compliant
- Yes
- Application
- Commercial
- Finish
- Polished Chrome
- Flow Rate
- 0.5 gpm
- Faucet Spout Shape
- Gooseneck
- Item
- Bathroom Sensor Faucet
- Number of Handles
- 0
- Body Material
- Cast Brass
- Voltage
- 12V AC
- Flow Outlet Type
- Laminar
- Residential / Commercial
- Commercial
- Faucet Type
- Bathroom Sink Faucet
- Sensor Range
- 3 in to 13 in
- Commercial / Residential
- Commercial
- Standards
- ADA ANSI/ICC A117.1, ASME A112.18.1/CSA B125.1, NSF/ANSI/CAN 61: Q Less Than or Equal To 1
- Connection
- 3/8" Female Compression
- Series
- HyTronic Gooseneck
- Power Source
- Hardwired
- Includes
- Mounting Hardware
- Vandal Resistant Features
- Vandal Resistant Outlet
- Ligature Resistant
- No
- Faucet Handle Type
- None
- Faucet Finish
- Chrome
- Mounting Type - Faucet
- Deck
- Temp. Control
- Yes
- CEC Compliant
- CEC Compliant
- Flow Outlet Type (Faucet)
- Laminar
- Faucet Spout
- Rigid
- ADA Compliance
- ADA Compliant
- Flow Outlet Type - Faucet
- Laminar
- Drain Type
- None
- Battery Charger CEC Compliant
- CEC Compliant
- Valve Type
- Metering
- Features
- Bluetooth Compatible
- Green Certification or Other Recognition
- California Energy Commission (CEC) Certified
- Type
- Electronic
- Water Inlet Connection Type
- Push in Compression
- Faucet Body Material
- Cast Brass
- Faucet Activation
- Motion Sensor
- Max. Mounting Hole Center Distance
- Single Hole
- Replacement Cartridge Mfr. Model Number
- 243.152.AB.1
- Spout Reach
- 5 1/4 in
- Valve Type - Faucets
- Solenoid Valve
- Temperature Control
- Adjustable Temperature
- Sensor Type
- Adjustable
- Material of Construction
- Cast Brass
- Outlet Type
- Laminar
- Warranty
- 1 yr Limited Finish Warranty, 3 yr Limited Electronics and Solenoid Warranty, 5 yr Limited Mechanical Warranty, Lifetime Warranty Metal Cast, Forged, Stamped of Formed Portion
- Includes Handle
- Handle Not Included
- Spout Shape
- Gooseneck
- Product Type
- Sensor Faucet
- Water Supply Type
- Hot and Cold Lines
- Temperature Control Method
- Above Deck Mixing Valve
- Sensor Range - Minimum
- 3 in
- Flow Type
- Spray
- Sensor Range - Maximum
- 13 in
- Vandal Resistance
- Vandal-Resistant Outlet
- Ligature Resistance
- Not Ligature-Resistant
- Spout Style
- Fixed
- Inlet Connection Type
- Compression
- Temperature - Maximum
- 140 Degrees F
- Operation Method
- Motion Sensor
- Number of Mounting Holes
- 1
- Pressure - Maximum
- 125 psi
- Includes Drain
- Drain Not Included
- Temperature - Minimum
- 40 Degrees F
- CEC Compliance
- CEC Compliant
- Flow Rate - Maximum
- 0.5 gpm
- Includes Transformer
- Transformer Not Included
- Time Out
- 40 sec
- Compatible Cartridge Manufacturer Part Number
- 243.152.AB.1
- For Location
- Bathroom
- Power Source - TS Only
- Hardwired
- Power Source - old
- Hardwired
