21PC 135 Degree Heavy-Duty Screw Machine Lngth Drill Set Chicago-Latrobe 159 Steam Oxide HSS 1/16-3/8x1/64

  • Mfr # 69852

  • Zoro # G0773412

product price:
$
88.19
/ea

Key Features

Number of Pieces
21
Cutting Direction
Right Hand
Drill Bit Point Angle
135 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
69852
Zoro #
G0773412
UPC #
662355698525
Country of Origin
United States

Dimensions

Depth:Dia. Ratio
4xD
Drill Bit Dimension Type
Fractional Inch
Drill Bit Size
1/16 in to 3/8 in by 64ths
Sizes Included
1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32", 15/64", 1/4", 17/64", 9/32", 19/64", 5/16", 21/64", 11/32", 23/64", 3/8"
Depth x Dia. Ratio
4xD
Size Range
1/16"-3/8"
Drill Length Class
Screw-Machine Length
Smallest Drill Bit Size
1/16 in
Largest Drill Bit Size
3/8 in
Drill Bit Sizes Included
1/16 in, 1/4 in, 1/8 in, 11/32 in, 11/64 in, 13/64 in, 15/64 in, 17/64 in, 19/64 in, 21/64 in, 23/64 in, 3/16 in, 3/32 in, 3/8 in, 5/16 in, 5/32 in, 5/64 in, 7/32 in, 7/64 in, 9/32 in, 9/64 in

Details

Item
Screw Machine Drill Bit Set
Number of Pieces
21
Cutting Direction
Right Hand
Drill Bit Point Angle
135 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
List Number
159
Application
For Alloy, Carbon And Tool Steels And Cast Iron
Point Type
Split Point
Standards
NAS 907 Type C
Drill Style
Screw Machine Drill
Primary Material Application
All Materials
Left/Right Hand
Right
Material - Machining
High Speed Steel
Finish - Machining
Black Oxide
Measurement System
Fractional Inch
Flute Type
Spiral
Shank Type
Straight
Shank Type - Machining
Straight
Number of Flutes
2
Coolant Fed
Non-Coolant Through
Number of Drill Bits
21
Material Grade - Machining
Heavy Duty
Drill Bit Point Type
Split Point
Drill Bit Case Type
Metal Index
Helix Angle - Minimum
21 Degrees
Helix Angle - Maximum
34 Degrees

Description

The CHICAGO-LATROBE 69852 Screw Machine Drill Bit Set includes 21 fractional-inch drill bits in the stated size range from 1/16" to 3/8". Made from high speed steel (HSS), these right-hand cutting drill bits have a 135° split point and include a metal drill index for storage and size identification. The screw-machine length bits have a black oxide finish and two spiral flutes; helix angles 21°–34°.

Key Features:

  • Number of pieces: 21 drill bits in assorted sizes from 1/16" to 3/8" by 64ths
  • Drill style: Screw machine length bits with straight shanks
  • Material: made from high speed steel (HSS)
  • Point type: 135° split point for reduced walking and accurate starts
  • Flutes: Two spiral flutes; helix angles 21°–34°
  • Cutting direction: Right-hand rotation
  • Finish: Black oxide coating
  • Includes a metal drill index for storage and size identification
  • Complies with NAS 907 Type C (per manufacturer specification)
  • Size range: 1/16" to 3/8" fractional inch measurements included
