  6. 47PC HSSPlugHandTap & CarbonRoundAdj. Die Set Cle-Line 21 Sizes 1/4-20 To 1-14 UNC, UNF, UNS & NPT
Cle-Line 47PC HSSPlugHandTap & CarbonRoundAdj. Die Set Cle-Line 21 Sizes 1/4-20 To 1-14 UNC, UNF, UNS & NPT C00532 - main
Shop CLE-LINE

47PC HSSPlugHandTap & CarbonRoundAdj. Die Set Cle-Line 21 Sizes 1/4-20 To 1-14 UNC, UNF, UNS & NPT

  • Mfr # C00532

  • Zoro # G2457192

product price:  $2,000.99
/ea
Free Shipping & Returns

Key Features

Sizes Included
1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-20, 9/16"-12, 9/16"-18, 5/8"-11, 5/8"-18, 3/4"-10, 3/4"-16, 7/8"-9, 7/8"-14, 1"-8, 1"-14, 1/8"-27 NPT
Number of Pieces
49
Material
High Speed Steel
Thread Direction
Right Hand
Type
Fractional
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
C00532
Zoro #
G2457192
UPC #
697334005322
Country of Origin
India

Dimensions

Sizes Included
1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-20, 9/16"-12, 9/16"-18, 5/8"-11, 5/8"-18, 3/4"-10, 3/4"-16, 7/8"-9, 7/8"-14, 1"-8, 1"-14, 1/8"-27 NPT
Size Range
1/4" to 1"
Cutting Sizes
21
Tap Dimension Type
Inch
Size/Range
1/4 to 1", 1/8" NPT
Tap Shank Dia.
Table 302
Min. Tap Thread Size
1/8"-27
Tap Overall Length
Table 302
Max. Die Thread Size
1"-14
Tap Sizes Included
1 in -8 NC, 1'-14 NS, 1/2 in -13 NC, 1/2 in -20 NF, 1/4 in -20 NC, 1/4 in -28 NF, 1/8 in -27 NPT, 3/4 in -10 NC, 3/4 in -16 NF, 3/8 in -16 NC, 3/8 in -24 NF, 5/16 in -18 NC, 5/16 in -24 NF, 5/8 in -11 NC, 5/8 in -18 NF, 7/16 in -14 NC, 7/16 in -20 NF, 7/8 in -14 NF, 7/8 in -9 NC, 9/16 in -12 NC, 9/16 in -18 NF
55% Thread Drill Size
#3, 1/2 in, 10.20mm, 11.30mm, 11.80mm, 11/32 in, 13.25mm, 14.20mm, 14.80mm, 15/16 in, 17.20mm, 17.90mm, 20.90mm, 29/32 in, 5.70mm, 51/64 in, 8.40mm, 9/32 in, I, W
65% Thread Drill Size
#5, 10.00mm, 11.00mm, 11.60mm, 12.50mm, 13.90mm, 13/16 in, 16.90mm, 17.70mm, 17/64 in, 23.60mm, 25/32 in, 33/64 in, 37/64 in, 57/64 in, 7/32 in, J, P, R, V
Max. Tap Thread Size
1"-14
75% Thread Drill Size
#7, 11.40mm, 12.20mm, 12.90mm, 13.60mm, 14.50mm, 16.50mm, 17.50mm, 19.50mm, 20.40mm, 22.25mm, 23.30mm, 27/64 in, 5.45mm, 5/16 in, 8.50mm, 9.95mm, F, I, U
Dimensions Standard
Fractional Inch
Die Thread Sizes Included
1'-14 NS, 1"-8 NC, 1/2"-13 NC, 1/2"-20 NF, 1/4"-20 NC, 1/4"-28 NF, 1/8"-27 NPT, 3/4"-10 NC, 3/4"-16 NF, 3/8"-16 NC, 3/8"-24 NF, 5/16"-18 NC, 5/16"-24 NF, 5/8"-11 NC, 5/8"-18 NF, 7/16"-14 NC, 7/16"-20 NF, 7/8"-14 NF, 7/8"-9 NC, 9/16"-12 NC, 9/16"-18 NF
Thread Sizes Included
1'-14 NS, 1"-8 NC, 1/2"-13 NC, 1/2"-20 NF, 1/4"-20 NC, 1/4"-28 NF, 1/8"-27 NPT, 3/4"-10 NC, 3/4"-16 NF, 3/8"-16 NC, 3/8"-24 NF, 5/16"-18 NC, 5/16"-24 NF, 5/8"-11 NC, 5/8"-18 NF, 7/16"-14 NC, 7/16"-20 NF, 7/8"-14 NF, 7/8"-9 NC, 9/16"-12 NC, 9/16"-18 NF
Min. Bore Dia.
1/8 in -27 NPT

Details

Item
Tap and Die Set
Number of Pieces
49
Material
High Speed Steel
Thread Direction
Right Hand
Type
Fractional
Thread Type
NPT, UNC, UNF, UNS
SAE or Metric
SAE
Includes
Tap, Die and Collet for Each Size, Steel Case with Foam Liner
Die Shape
Round
Tap Chamfer
Plug, Taper
Die Type
Adjustable
Standards
ANSI
Tap Material
High Speed Steel
Finish
Mill
Left/Right Hand
Right Hand
Tap Wrench Number
#5, #7
Die Material
High Speed Steel
Tap Finish
Bright (Uncoated)
Features
General Purpose Applications
Number of Flutes
4
Material - Machining
High Speed Steel
Secondary Material Application
Stainless Steel
Tap Type
Hand Tap
Class of Fit
2B
Finish - Machining
Bright (Uncoated)
Number Of Taps
21
Primary Material Application ISO Code
H, K, M, N, P, S
Die Material Grade
Carbon Steel
Secondary Material Application ISO Code
M
Primary Material Application
All Materials
Spiral Direction
Neutral
Powdered Metal Base Material
No
Number of Dies in Set
21
Extension Tap
No
Coolant Fed
Non-Coolant Through
Case Type
Metal
Helix Angle
0 Degrees
Extended Shank
No
Die Series
0610
Thread Standard
NPT, UNC, UNF, UNS
Thread Limit
H3, H4
Measurement System
Fractional Inch
Die Finish
Bright (Uncoated)
Tap Shank Standard
Table 302
Threads per Inch
8, 9, 10, 11, 12, 13, 14, 16, 18, 20, 24, 27, 28
Tap Series
411
Extended Neck
No
Tap Material Grade
M2

Description

Tap and Die Set, Number of Pieces 47, Die Shape Round, Tap Type Hand Tap, Die Material Carbon Steel, Thread Sizes Included 1 In.-14, 1 In.-8, 1/2 In.-13, 1/2 In.-20, 1/4 In.-20, 1/4 In.-28, 1/8 In.-27, 3/4 In.-10, 3/4 In.-16, 3/8 In.-16, 3/8 In.-24, 5/16 In.-18, 5/16 In.-24, 5/8 In.-11, 5/8 In.-18, 7/16 In.-14, 7/16 In.-20, 7/8 In.-14, 7/8 In.-9, 9/16 In.-12, 9/16 In.-18
