This item is Discontinued.
Commscope Replacement for Commscope Ava5-50 AVA5-50 COMMSCOPE

Replacement for Commscope Ava5-50 (Discontinued)

  • Mfr # AVA5-50 COMMSCOPE
  • Zoro # G002959976
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AVA5-50 COMMSCOPE
Zoro #
G002959976
UPC #
-
Country of Origin
United States

Dimensions

Nominal Size
7/8 in
Diameter Over Dielectric
24.13 mm | 0.95 in
Diameter Over Jacket
27.991 mm | 1.102 in

Details

Capacitance
73 pF/m | 22.25 pF/ft
dc Resistance Inner Conductor
1.435 ohms/km | 0.437 ohms/kft
dc Test Voltage
6000 V
dc Resistance Outer Conductor
1.116 ohms/km | 0.34 ohms/kft
Number of Bends typical
30
Frequency
Attenuation (dB/100 m)
Operating Frequency Band
1 - 5000 MHz
Outer Conductor OD
25.4 mm | 1 in
Cable Impedance
50 ohm ±1 ohm
Bending Moment
19 N-m | 168.164 in lb
Flexibility
Standard
Number of Bends minimum
15
Product Series
AVA5-50
Inner Conductor OD
9.4488 mm | 0.372 in
Jacket Color
Black
Outer Conductor Material
Corrugated copper
Operating Temperature
-55 °C to +85 °C (-67 °F to +185 °F)
Jacket Material
PE
Peak Power
91 kW
Insulation Resistance
100000 MOhms-km
Inner Conductor Material
Copper tube
Dielectric Material
Foam PE
Flat Plate Crush Strength
1.3 kg/mm | 72.797 lb/in
Storage Temperature
-70 °C to +85 °C (-94 °F to +185 °F)

Description

Replacement for Commscope Ava5-50
