Specifications
Product Information
MFR #
78EZDF
Zoro #
G102912451
UPC #
-
Country of Origin
Mexico
Dimensions
Length
47.16 mm | 1.857 in
Nominal Size
7/8 in
Diameter
37 mm | 1.457 in
Details
Attachment Durability
25 cycles
Pressurizable
No
Insulation Resistance minimum
5000 mOhm
Body Style
Straight
Interface
7-16 DIN Female
dc Test Voltage
4000 V
Operating Frequency Band
0 - 5000 MHz
Connector Impedance
50 ohm
Cable Impedance
50 ohm
Mounting Angle
Straight
Peak Power maximum
40 kW
Storage Temperature
-55 °C to +85 °C (-67 °F to +185 °F)
Inner Contact Plating
Silver
Connector Retention Torque
8.14 N-m | 72.001 in lb
Connector Retention Tensile Force
1334.47 N | 300.000 lbf
Outer Contact Plating
Trimetal
Product Series
AVA5-50 | AVA5-50FX | AVA5RK-50
Operating Temperature
-40 °C to +85 °C (-40 °F to +185 °F)
Interface Durability
50 cycles
Description
Replacement for Tessco 78ezdf
